Operating the Chair

4.0 Unfolding the Chair

The chair folds for shipping and stowage when the Track is
not attached.
1. Undo the restraint strap (if used), unfold by placing the
Chair on the ground and pulling the rear handle from the
lower handle.
Figure 4 - Unfolding the Chair for use
2. Completely unfold by firmly pushing up the back until
an audible click is heard.
Figure 5 - Lifting up back rest whilst applying force to
8
4 - OPERATING THE CHAIR
the foot rest
3. Once the chair is locked secure, move both of the safety
rings down over the hinge bracket.

Figure 6 - Securing the chair by deploying safety rings

Figure 7 - Chair deployed and ready for use without
© Ferno (UK) Ltd. FERNO/MAN/R5/08/18/207/UK
Compact 2 Track Chair
Track
