Compact 2 Track Chair

4.1 Folding the Chair

Before folding, fully lower the upper handle if it is raised
(see 'Adjusting Upper Handle Height') and remove the track
if it is attached (see 'Removing the Track').
1. Push the Safety Rings up over each hinge bracket

Figure 8 - Removing safety rings so Chair can fold

2. From behind the Chair, release the locking bar (in the
centre of the chair frame) by lifting the bar towards you,
either by hand or foot and carefully fold the Chair forwards.
Figure 9 - Release the locking bar to allow Chair to fold
© Ferno (UK) Ltd. FERNO/MAN/R5/08/18/207/UK
3. Push in a downward direction on the upper handle
to fold the lower handle upwards in reaction to the
downward force.

Figure 10 - Folding the Chair ready for stowage

4. The patient restraints should be used to secure the Chair
in the folded position.
Figure 11 - Chair folded and fastened secure for
stowage
Operating the Chair
9
