Error messages and operating-status details are shown as plain text on the LCD.
These messages are described below:
Status displays:
System test
CHRG 12V on
24V CHRG on
Pb no contact
LIO no contact
Start CHRG mode? Prompt to start charging mode if auto start is disabled (section10.8)
12V Pb charge
12V LIO charge
Charge 24V on
Pb 12V standby
LIO 12V standby
CHRG 24V standby 24V battery charging on standby (section 6.2)
12V Shutdown
Shutdown ok
Refresh Start?
Refresh Stop?
Battery full
Max. CHRG time
Start EPS-12V?
Start EPS 24V?
Stop EPS-12V?
Stop EPS 24V?
Auto. start EPS
No EPS contact
Error messages:
Mains error
PFC error
Overvoltage
OVP error
Voltage too low
Overcurrent
Temperature err.
Internal error
Short circuit
Reverse polarity
Faulty battery
Clamp contact
Return voltage
EPS reverse pole
Shutdown error
Refresh error
2280073 Rev.1
Status and error descriptions
Status and error descriptions
Internal test routines in progress
Mode prior to start of charging process (section 6.2, section 6.6)
Mode prior to start of charging process (section 6.2)
No battery connected (section 6.2)
No battery connected (section 6.6)
12V charging of lead-acid battery in progress (section 6.2)
12V charging of lithium-ion battery in progress (section 6.6)
24V battery charging in progress (section 6.2)
12V battery charging on standby (section 6.2)
12 V battery charging on standby (section 6.6)
Test if the battery contactor (disconnecting switch) is closed, only for
lithium-ion batteries (section 7.5)
Evaluation if the battery contactor (disconnecting switch) is closed, only
for lithium-ion batteries (section 7.5)
Prompt to start refresh (section 7.4)
Prompt to stop refresh (section 7.4)
Battery fully charged before end of maximum charging time (section 6.2,
section 6.6)
Maximum charging time over, battery not fully charged (section 6.2,
section 6.6)
Prompt to start 12V EPS mode (section 6.8)
Prompt to start 24V EPS mode (section 6.8)
Prompt to stop 12V EPS mode (section 6.8)
Prompt to stop 24V EPS mode (section 6.8)
EPS autostart mode (section 6.9)
No battery connected in EPS autostart mode (section 6.9)
No mains voltage lower than 85V (section 8.1)
Intermediate-circuit voltage is incorrect (section 8.2)
Output voltage too high (section 8.3)
Output voltage too high (section 8.3)
Output voltage too low (section 8.4)
Output current too high (section 8.5)
Internal temperature too high (section 8.6)
Internal defect in the charger (section 8.7)
Short circuit at the output (section 9.1)
Battery reversely connected (section 9.2)
Voltage of connected battery not allowed (section 9.3)
No connection between battery and MultiCharger 1500 (section 9.4)
Battery connected in EPS mode (section 9.5)
Battery reversely connected in EPS mode (section 9.6)
Evaluation that the battery's disconnecting switch is not closed, only for
lithium-ion batteries (section 9.7)
Evaluation that the battery's disconnecting switch is not closed, only for
lithium-ion batteries (section 9.8)
