Factory (Default) Settings; Select Language - Eltek MultiCharger 1500 Description And Operating Instructions

Factory (default) settings

Factory (default) settings
Selecting the "Factory settings" menu and pressing the "Enter" key restores the following
parameters to their default settings.
12V Pb charging voltage
12V LIO charging voltage
24V charging voltage
12V Pb trickle charge voltage : 13.4V
12V LIO trickle charge voltage : 13.4V
24V trickle charge voltage
Shutdown voltage
Refresh voltage
12V EPS voltage
24V EPS voltage
12V charging current limit
24V charging current limit
12V EPS current limit
24V EPS current limit
12V Ua max.
24V Ua max.
12V Ua min.
24V Ua min.
Switch back delay
Maximum charging time
Current limit 2
Operating mode
Autostart
24V operating modes
The MC1500 provides the option to make permanent changes to the default settings through
external software. In this case, the charger's settings may vary from those shown above.
If the default settings are changed, this should be marked in the accompanying documentation.

Select language

The "Select language" menu can be used to select one of the following languages:
- German
- English
- French
- Dutch
- Italian
- Spanish
- Finnish
Each language is shown on the selection menu in that particular language.
2280073 Rev.1
: 14.8V
: 14.0V
: 28.8V
: 26.8V
: 11.0V
: 14.0V
: 14.2V
: 28.0V
: 80.0A/100.0A
: 40.0A/50.0A
: 80.0A
: 40.0A
: 16.0V
: 32.0V
: 7.0V
: 14.0V
: 005min
: 12h
: 3.0A
: battery charging mode 12V Pb
: enabled
: off
Page 44
