Service menu
1
Set current limit
Set I-limit
I-limit CHRG 12V
CHRG12V
Now at: 80A/100A
Set I-limit
I-limit CHRG 24V
CHRG24V
Now at: 40A/50A
I-limit EPS 12V
Set I-limit EPS 12V
Now at: 80A
I-limit EPS 24V
Set I-limit EPS 24V
Now at: 40A
Exit menu
2280073 Rev.1
Structure of service menu
Set process times
Set switch back
Switch back time
time
Now at: 005min
Set maximum
Max. CHRG time
charging time
Now at: 12hrs
Set I-limit 2
Ilimit 2
Now at: 03A
Exit menu
Set wire resistance
Turn on/off
autostart
Wire resistance
Autostart
Now at: 015mOhm
now enabled
Autostart
now disabled
Page 34
2
