2 Getting started
2.2.3
Understanding the ICS AirCal Back Panel
Note
•
The USB port
2.2.3.1
Connecting the Foot Switch
The foot switch comes standard with the ICS AirCal. Connect the foot switch to the back of the irrigator
ICS AirCal is connected to an ICS VNG/ENG system and you want to use the foot switch to start tests other than the caloric
test, you need to have the irrigator on in order to use the foot switch.
2.2.3.2
Connecting to an ICS VNG/ENG system
The ICS AirCal can be connected to an ICS VNG/ENG system. Connect the irrigator cable to the back of the irrigator
and to the ICS VNG/ENG system.
Connecting the 2 devices together gives additional functionality. See
ation.
2.2.3.3
Connecting the Mains power cable
The ICS AirCal should be connected to an electrical wall outlet by attaching the power cable to the ICS AirCal irrigator and
plugging the cable into the electrical wall outlet.
8
allows for firmware upgrades. Refer to
►
Firmware procedures
35
Activation Trigger Operation
. If the
►
19
for more inform-
Otometrics - ICS AirCal
