Pump Handle
Turn clockwise only to
dispose of oil.
DO'S
Do clean crumb tray
and inside tank.
Turn the pump handle
only clockwise.
DON'TS
Don't fill with
water or use
to drain boilout solu-
tion.
Don't move without
the handle bolted in
place.
Don't use
without
the crumb tray.
Don't overfill.
Don't move with the
lid unlatched.
Don't leave oil in the
tank.
Crumb Tray
Ensure the crumb tray
is present and clean.
01/2018
SDU 100
Spout Locking Pin
Release to pivot spout toward
disposal vessel.
Handle Locking Pins
Ensure bolts are in place before
moving the SDU.
USING AN SDU
See assembly, initial setup on back page
• Place the open tank under
the drain valve or drain exten-
sion of a fryer. Ensure the fryer
is off and the oil is no more
than 100°F (38°C).
• Slowly open the drain valve.
Fill only to the fill line on the
tank. Drain only one vat at a
time.
• Close and secure the lid of
the SDU. Roll it to the disposal
site. Rotate the pump's spout
by lifting the spout locking
pin. Locate the spout over the
disposal vessel.
• Turn the crank clockwise to
dispose of the oil.
Tank
Do not fill above marked fill
line; do not move without the lid
securely clasped and the gasket
in place.
