Direct Steam
Table Top Kettles
Installation, Operation, Maintenance, Parts & Service
This manual is updated as new information and models are released. Visit our website for the latest manual.
MODELS:
KDT-1-T
KDT-3-T
KDT-6-T
KDT-12-T
KDT-20-T
Read the manual thoroughly.
!
Improper installation, operation or
maintenance can cause property
damage, injury or death.
TABLE OF CONTENTS
Statement of Responsibilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
For your Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Service Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Part # - KE004008-2 B August 2019
For your future reference.
Model # ______________________________________
Serial # ___________ ____________________________
Model # &
Serial #.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Welbilt Cleaveland KDT-1-T
Summary of Contents for Welbilt Cleaveland KDT-1-T
- Page 1 Visit www.clevelandrange.com to locate a service or sales representative in your area. Direct Steam Table Top Kettles Installation, Operation, Maintenance, Parts & Service This manual is updated as new information and models are released. Visit our website for the latest manual. MODELS: For your future reference.
-
Page 2: Statement Of Responsibilities
STATEMENT OF RESPONSIBILITIES / DÉCLARATION DES RESPONSABILITÉS / DECLARACIÓN DE RESPONSABILIDADES This document is for use by experienced Ce document est destiné à l’usage des Este documento está destinado para el uso and trained Qualified Cleveland Range, Représentants de Service qualifiés et de los Representantes de Servicio LLC Authorized Service Representatives autorisés de Cleveland Range, LLC qui... -
Page 3: For Your Safety
FOR YOUR SAFETY / POUR VOTRE SÉCURITÉ / PARA SU SEGURIDAD FOR YOUR SAFETY POUR VOTRE SÉCURITÉ PARA SU SEGURIDAD Do not store or use Ne pas entreposer ou No guarde ni use gasolina gasoline or any other utiliser d'essence ou o cualesquiera otros flammable liquids and d'autres liquides ou... - Page 4 WARNING / AVERTISSEMENT / ADVERTENCIA Improper installation, operation, adjustment, alteration, Heavy / Lourd / Pesado service or maintenance can cause property damage, Team or mechanical lift. / Équipe ou remontée injury or death. Read the installation and operating mécanique. / Equipo o elevador mecánico. instructions thoroughly before installing, operating or servicing this equipment.
-
Page 5: Maintenance
MAINTENANCE ALL SERVICE MUST BE PERFORMED BY A QUALIFIED SERVICE TECHNICIAN. This kettle requires very little preventative maintenance other than daily cleaning. The pressure relief valve must be tested twice a year. PRESSURE MARINE LOCK RELIEF Inspect lock at least twice yearly. VALVE 1. - Page 6 TROUBLESHOOTING GUIDE This section contains information intended for use by Authorized Service Personnel only. PROBLEM A/ Kettle heats too slowly or does not come to a boil. Probable Cause Remedy 1. Inadequate steam flow. Check for correct steam using chart below. If kettle is connected to a steamer and powered by a generator the units should be operated sequentially (kettle boiling first, then start steamer).
-
Page 7: Service Parts
SERVICE PARTS WARRANTY Our Company supports a worldwide network of Maintenance and Repair Centers. Contact your nearest Maintenance and Repair Centre for replacement parts, service, or information regarding the proper maintenance and repair of your cooking equipment. In order to preserve the various agency safety certification (UL, NSF, ASME/Ntl. Bd., etc.), only factory-supplied replacement parts should be used. The use of other than factory supplied replacement parts will void warranty. - Page 8 Page 2 of 2 FAUCETS Models FAUCET BRACKET SPOUT KDT12/20 ON SD TABLE SPK1 KE50825-1 DPK1 KDL60/80/100T SPK2 KE54159 KE50825-2 KEL40/60/80/100T DPK2 KE02071-1 (CP) KET20 KGT,MKET, KDP60-100/T KDL25/40T SPK3 KE54159 KE50825-3 KEL25T,KDP25/40T DPK3 KDM60/T SPK-KDM60 KE50825-2 DPK-KDM60 KDM25/40/T SPK6 KE50825-6 DPK6 KDL40/60/80TSH SPK7...
- Page 9 STEAM CONTROL ASSEMBLY FOR KETTLES WITHOUT GEARBOX (KDT-1/3/6/12/20-T)
- Page 10 STEAM CONTROL ASSEMBLY ITEM NO. PART NO. DESCRIPTION QTY. FA11056 Binding Head Screw, 6-32 x 1/2" lg........4 T80262 End Cap, condensate return, KDT-1-T, .
- Page 11 TILTING GEARBOX ASSEMBLY - FOR KETTLES WITH GEARBOX (KDT-12/20-TGB) To part #18 To part #22 See “STEAM CONTROL NOTE: Item #14 to be tack ASSEMBLIES FOR KETTLES welded flush outside in the WITH GEARBOX” gearbox housing (item #1). Do not damage the outside edges of the gearbox housing when tack welding.
- Page 12 To learn how Welbilt Foodservice and its leading brands can equip you, visit our global web site at www.welbilt.com, then discover the regional or local resources available to you. ©2016 Welbilt Foodservice except where explicitly stated otherwise. All rights reserved. Con nuing product improvement may necessitate change of specifia ons without no ce.
