3.3.3. Wireless keypads
Step 1: Register a wireless keypad
The Prime supports up to four wireless keypads.
1.
Go to the main menu, select [9]>[1]>[3] (Programming > Devices > Keypads) .
2.
Select the keypad to register and press '√ʹ. The system initiates Registration mode.
3.
Press a button on the keypad assuring that a LED lights up when the button is pressed.
4.
Press the same button again. When 'Save?' appears on the Control System's LCD display,
press '√ʹ.
5.
Set the keypad descriptor.
Note:
The above procedure refers to keypad EL2620 AND EL 2640. For registration keypads
EL2621, EL2724, refer to the full installer manual.
Step 2: Test a keypad
1.
Go to the main display and press '√ʹ.
2.
Enter your Installer code (default code '1111').
3.
Enter [7]>[07]>[2] (Service > Transmitters > TX Test) to initiate the TX communication
test. Review the explanation in Detectors section.
10
