Electronics Line Summit 3208GLD Installation, Operation, And Programming Manual

Hide thumbs Also See for Summit 3208GLD:
Table of Contents

Advertisement

Quick Links

See also: User Manual
E L E C T R O N I C S L I N E ' S T E C H N I C A L S U P P O R T D E P A R T M E N T : (972)-3-9211110
Electronics Line (E.L.) Ltd. reserves the right to change the information within this manual without prior notice.
Installation, Operation
Installation, Operation
Electronics Line (E.L.) Ltd.
www.elecline.com
Summit
Summit
3208GLD
3208GLD
and Programming
and Programming
ZI0084A (12/98)

Advertisement

Table of Contents
loading

Related Manuals for Electronics Line Summit 3208GLD

Summary of Contents for Electronics Line Summit 3208GLD

  • Page 1 E L E C T R O N I C S L I N E ’ S T E C H N I C A L S U P P O R T D E P A R T M E N T : (972)-3-9211110 Electronics Line (E.L.) Ltd. reserves the right to change the information within this manual without prior notice.

  • Page 3: Table Of Contents

    About the Summit 3208GLD Installation, Operation and Programming Manual This manual is designed to help you, the installer, with the installation process for the Summit 3208GLD We strongly urge you to read through this manual, in its entirety, before beginning the installation process so that you can best understand all that this security system has to offer your customers.

  • Page 4: Chapter One: Overview

    HAPTER VERVIEW 1.1: Specifications AC: 15Vac, 30VA transformer. Power Input Battery backup: 12Vdc, 6.5 Ah or 7Ah (UL requirement). Power Output Auxiliary power - regulated 12Vdc nominal at 1A max. including keypads and detection devices for 4 hours standby. (For CSFM Fire applications - 220mA max. including keypads and smoke detectors for 24 hours standby).

  • Page 5: Zones

    1.2: Zones The Summit 3208GLD comprises 8 on-board zones that are expandable to a total of 32. Both hardwire and wireless zone expanders are available. Each zone can be precisely configured to suit a wide variety of applications. Zone Descriptors Each zone can be assigned an individual zone descriptor.

  • Page 6: Telephone Dialer

    1.3: Telephone Dialer The Summit 3208GLD allows for up to four different telephone numbers to be programmed into the system using either pulse or tone dialing. The Summit 3208GLD supports several communication protocols including pulse protocols enabling communication with most popular central station receivers.

  • Page 7: Other Features

    ‘Failed to Open’ or ‘Failed to Close’ message is sent to the central station. The Summit 3208GLD offers the opportunity to choose from a list comprising three opening and four closing window times. The times in this list can be programmed according to the user’s entry and exit scheduling requirements.

  • Page 8: Chapter Two: Installation

    HAPTER NSTALLATION 2.1: Parts and Options Standard Parts Summit 3208GLD Household Burglary Alarm Control Panel without keypad 1 each 2.2K ohm burglary End Of Line Resistors 8 each Installation, Operation, and Programming Manual 1 each User Manual 1 each Optional Parts List...
  • Page 9 Keypad Wiring Connections LSCP GND VDD CONTROL PANEL WHITE GREEN BLACK KEYPAD LSCP Keypad unit address Up to eight individually addressed supervised keypads can be installed with the control panel. If more than one keypad is installed with same unit address, all keypads must be configured as unsupervised. To configure the keypad unit address: 1.

  • Page 10: Wiring Diagram

    2.3: Wiring Diagram Electronics Line (E.L.) Ltd. For Future Use Long Range 12V/7Ah SUMMIT 3208GLD Radio BATTERY Interface Household Burglary and Fire Alarm Panel Connector POWERSONIC PROTECTION FUSES PS-1270 or TELCOM F1 (BATT): 3A/250V Factory YUASA NP7-12 1 & 2: Outgoing line to telephone...

  • Page 11: Terminal Connections

    2.4: Terminal Connections Telephone Connections Connector J4: The telephone line should be connected as follows: Incoming Line from Telephone Company Home Tip Outgoing Line Outgoing Line to Telephone Earth to Telephone Home Ring -Or- Incoming Line from Telephone Company Telco Ring 8-Position Telephone Socke On-Board Relay Contacts Terminals 1, 2, 3 and 4:...

  • Page 12: Fuse Replacement

    2.5: Fuse Replacement There are 3 protection fuses on the Summit 3208GLD control panel board, the layout of the fuses is shown in the following diagram: Battery Protection Fuse 3 Amp / 250V Bell Power Output Protection Fuse 3 Amp / 250V...

  • Page 13: Chapter Three: System Operation For The 3106 Led And 3108 Lcd Keypads

    EYPADS 3.1: General The Summit 3208GLD can be operated by using either the 3108 LCD or 3106 LED keypads. All the parameters can be programmed using either the LCD keypad or the Remote Programmer software. Refer to Chapter Four: Programming, page 23, for instructions relating to programming the system.

  • Page 14: System Status Displays

    Keys and Keypad Functions 0 - 9: The numeric keys are used to enter user codes, telephone numbers, to issue commands and for numeric programming. Q , #: These keys are used in programming the control panel. Pressing the Q key during the exit delay cancels the delay, immediately arming the system.

  • Page 15: Menu Selections/Direct Commands

    Zone Status Display Zone status will only be displayed if detailed display is selected Zone 1, Bedroom, is open Z O N E 1 O P E N B E D R O O M Zone 3, Front Door, has been bypassed Z O N E 3 B Y P A S S E D F R O N T D O O R Zone 4 has been tampered with...

  • Page 16: Arming/Disarming

    The ability to force arm the system is optional and is selected at address 494. Note: Electronics Line recommends waiting until all of the zones are secured and the system can be armed normally.

  • Page 17: User Codes

    Immediate Arming The system can be immediately armed, canceling the entry or exit delay for the arming period. To arm the system immediately: • Press Q during the exit delay; the delay is cancelled and the system is armed immediately. Note: Immediate arming disables both the exit and entry delays for the arming period.

  • Page 18: Zone Bypassing/Unbypassing

    User codes and system partitioning When the Summit 3208GLD is partitioned into several sub-systems, user codes can be associated either with a specific sub-system or with the entire system. Assigning a user code to only one system will default all operations to that system.

  • Page 19: Event Log

    Log also causes the Armed LED to stop flashing and zone in alarm messages to be cleared. 3.10: System Partitioning The Summit 3208GLD can be operated in partitioned mode where the system is separated into a maximum of four sub-systems. A sub-system is created when at least one zone has been assigned to it. The following section describes how certain elements of the system are affected by system partitioning.

  • Page 20: Tests

    3.11: Tests Walk Test The walk test allows detection devices to be tested without generating an alarm. To perform a walk test: 1. Press SELECT 4, 2, 1 or select Walk Test from the Test menu. 2. Test the control panel’s detection devices; an opened zone causes the keypad to beep. 3.
  • Page 21 Bell Cancel The bell is automatically stopped when the system is disarmed. To stop the bell manually: 1. On the LCD keypad, press SELECT 4, 4; the panel prompts you to enter a user code. 2. Enter an authorized user code; the bell stops ringing immediately and the system sends a Bell Cancel event code to the central station.
  • Page 22 Latch Key When the latch key feature is activated (address 411), the MENU/NEXT key is used to acknowledge arrivals or departures from the system during opening or closing windows. If MENU/NEXT is not pressed after the user code is entered, a ‘Failed to Open’ or ‘Failed to Close’ event code is sent to the central station. Zone Chime A zone can be programmed to chime when opened.

  • Page 23: Chapter Four: Programming

    ROGRAMMING 4.1: General The Summit 3208GLD control panel can be programmed using either the 3108 LCD keypad or the Remote Programmer, Electronics Line’s up/downloading software. For keypad operation refer to Chapter 3. For programming using the Remote Programmer refer to the instructions provided with the software. Contact your nearest Electronics Line office or agent to obtain a copy of the software.

  • Page 24: Programming Parameters

    # to change the digit to A. If the original digit is hexadecimal (A-F), press # to move to the next hexadecimal digit in sequence. 4.4: Programming Parameters This section comprises a complete listing of the Summit 3208GLD control panel’s programming parameters. The following table lists the addresses for each group of programming parameters. ADDRESSES...
  • Page 25 ADDRESSES 000-127: ZONE PARAMETERS 000-003: Zone # 1 Parameters Each zone is individually defined in four parameter addresses. The following four addresses relate to zone 1 but the method of programming zones 2 - 32 is identical. LCD Zone Descriptor and Entry Delay for Zone #1 Select a zone descriptor and entry delay for zone 1 from the table below.
  • Page 26 First Digit: Loop Speed, Pulse Count and Swinger Setting for zone # 1 The following table lists the options for the loop speed, pulse count and swinger setting. A slow loop response (150ms) should be entered for motion sensors and contacts. Enter a fast loop response (50ms) for shock sensors.
  • Page 27 Second Digit: Listen-In, Event Code Transmission to the Central Station and Bell Activation Select the type of output for this zone in the event of an alarm. Second digit value: Listen-In Send Message to Activate Value Activated Central Station Bell 004-007 Same as above for zone #2 008-011...
  • Page 28 ADDRESSES 128 – 131: SYSTEM PARAMETERS These addresses offer a number of options for each sub-system. The keypad tones (beeps) and one-key arming feature for each sub-system can be set at these addresses. Program only system 1 for unpartitioned systems. First Digit: Keypad Arming/Disarming Tones for System #1 Each sub-system’s keypads can be programmed to beep during arming, disarming and during the entry delay.
  • Page 29 ADDRESSES 132 – 139: KEYPAD PARAMETERS The following addresses offer options for the configuration of each keypad. First Digit: Backlight and Buzzer Operation for Keypad # 1 Select the backlight and buzzer options from the following table. First digit value: Buzzer Backlight Value...
  • Page 30 ADDRESSES 180 - 195: ACCOUNT NUMBERS Account numbers are transmitted to the central station with the event code to identify the source of the event. Each system can be given a separate account number. If the system is not partitioned, only enter the account number for System 1.
  • Page 31 The default value for the second digit of this parameter has been chosen according to the requirements of the local telecommunications authority. If any problems are experienced, please contact Electronics Line Technical Support Dept. Second digit value: 0 - Dial after 1 second, 2 second anti-jam...
  • Page 32 ADDRESSES 198 - 201: COMMUNICATION PROTOCOLS Each of the four telephone numbers is associated with a telephone communication protocol programmable at these addresses. These can be defined according to the protocol used in communications with the central station and whether the message sent will be from either the zone or event oriented event code tables.
  • Page 33 The following are the addresses for zone oriented event code messages. For event oriented codes refer to addresses 262 - 295. Event code for zone restore Event code for zone 1 Event code for zone 2 Event code for zone 3 Event code for zone 4 Event code for zone 5 Event code for zone 6...
  • Page 34 Event code for user initiated bell cutoff Event code for “E” button Event code for “F” button Event code for “P” button Event code for keypad emergency restore Event code for duress Event code for periodic test Note: This event code is reported with user code 0. Event code for system initialization ADDRESSES 262 - 295: EVENT ORIENTED EVENT CODE TABLE The following is a guide to programming event codes.
  • Page 35 ADDRESSES 296-310: EVENT & MESSAGE ROUTING Event code messages can be routed in several ways. Each telephone number can be set as a primary, back-up or duplicate number for a specific group of events. The control panel can also be programmed not to dial a certain telephone number for certain events.
  • Page 36 299-301 Message routing for LSCP unit trouble messages Same as addresses 296 – 298 302-304 Message routings for fire trouble messages Same as addresses 296 - 298 Note: Fire zones have a fixed bell pattern - pulse on and off for half a second in groups of three with an interval of one and a half seconds between each sequence.
  • Page 37 ADDRESS 388: SWINGER PARAMETERS Swinger mode. Defining a zone as a Swinger limits the number of alarms that can be generated from that zone within a pre-programmed amount of time. Each zone can be programmed with its Swinger option active. All swinger zones are assigned the same swinger setting.
  • Page 38 396-409 Daily Windows Settings A different combination of windows can be programmed for each day of the week and for each system. Select a value for each digit of these addresses from the following table. Open Close Value Open Close Value No Windows MONDAY...
  • Page 39 ADDRESSES 412-475: CUSTOM LCD ZONE DESCRIPTORS Four of the descriptors that can be assigned to each zone (see Address 000) can be customized to suit a specific installation. A total of sixteen characters, including spaces, can be entered for each LCD custom zone descriptor using the following table.
  • Page 40 ADDRESSES 477-490: RELAY PARAMETERS Output relay modules are optional add-on peripherals that are connected to the control panel via the LSCP bus. Relays can be used for various purposes including status indication, additional bell outputs and access control. Each individual relay is programmed at two addresses. Operation Mode Relay 1(and onboard relay K5) Each relay can be programmed to activate or deactivate based on specific events or status conditions.
  • Page 41 Output and Cutoff Relay 1(and onboard relay K5) The second address concerns the following characteristics of the relay’s operation. • Polarity – the relay’s status when deactivated • Output – how the relay acts when activated • Cutoff – the duration for which the relay is activated First digit value: Output Polarity...
  • Page 42 Periodic Test Time Setting (Hour) The periodic test time is set at two addresses, 492 and 493. The hour at which the test will take place is programmed at this address. Note: If either the 6-hour or 12-hour test has been programmed this is the time of the first test.
  • Page 43 First Digit: Detailed Display The keypad can be programmed to show the detailed display at all times or only when the system is disarmed. First digit value: 0 – Detailed display only when system disarmed. 1 – Detailed display at all times. Second Digit: Fire Sensor Reset and Bell Muting for Listen-In Applications The second digit of this address concerns the following: •...
  • Page 44 ADDRESSES 497-498: AC LOSS & RESTORE AC loss report delay. The AC loss report delay determines how many minutes the panel will wait after AC power has been lost before transmitting a message to the central station. Select a value in hexadecimal for the AC loss report delay.

  • Page 45: Appendix A: Troubleshooting

    A: T PPENDIX ROUBLESHOOTING The following is a guide to troubleshooting, using the Summit 3208GLD security system. Problem Reason Action Telephone line failure appears Event codes programmed at Program event codes as “00” and when the telephone line is not values above “00”.

  • Page 46: Appendix B: Hexadecimal Conversion Chart

    B: H PPENDIX EXADECIMAL ONVERSION HART The following is a decimal (i.e. number of hours, minutes, etc.) to hexadecimal conversion chart:...

  • Page 47: Glossary

    LOSSARY 24 hr zone A zone which is always active regardless of whether the system is armed or disarmed. Opening a 24hr zone always generates an alarm. The disruption of AC power. AC Loss The number transmitted to the central station along with an event code to identify the source Account Number of the event.
  • Page 48 See Protocol. Communication Protocol Conditional Zone A zone that will not generate an alarm during the entry delay. An option that disables the default restore code “123456”. Dealer Lockout The default program contains the factory parameter settings. For typical installations, the Default Program default program minimizes the amount of programming that needs to be performed by the installer.
  • Page 49 A feature designed to inform parents whether their children have arrived home safely. The Latch Key panel sends a message to the central station and/or the follow-me number if MENU/NEXT is not pressed during the appropriate window. Late to Close A command that extends the closing window period if the system needs to be armed later than usual –...
  • Page 50 A keypad display mode without zone status – see Detailed Display. Summarized Display Supervised A supervised keypad generates an alarm when disconnected from the control panel. Keypad A zone from which the number of alarms sent within a predetermined time period is limited. Swinger Zone A manual test that checks the control panel’s ability to communicate with all programmed Telephone Com-...
  • Page 51 ELECTRONICS LINE (E. L.) LTD. AND ITS SUBSIDIARIES - LIMITED WARRANTY ELECTRONICS LINE (E. L.) LTD. AND ITS SUBSIDIARIES (EL) warrants its products to be free from manufacturing defects in materials and workmanship for two years following the date of sale. EL will, within said period, at its option, repair or replace any product failing to operate correctly without charge to the original purchaser or user.
