Summary of Contents for Electronics Line Penta

  • Page 2: Table Of Contents

    Index ........................ 28 Introduction This manual is designed to help you with the installation process for the Penta control panel. We strongly urge you to read through this manual, in its entirety, before beginning the installation process so that you can best understand all that this security system has to offer your customers.

  • Page 3: Chapter One: Overview

    Temperature 1.2: Zones The Penta control panel includes four security zones plus one tamper zone which can be defined for use with an ON/OFF keyswitch. The four security zones are fully pro- grammable and supervised by end of line resistors. The Penta offers five zone response types for customized programming to suit a wide range of installations.

  • Page 4: Telephone Communication

    1.3: Telephone Communication The Penta allows for up to two telephone numbers (primary and backup) to be programmed into the system dedicated to central station communications or for use with the ‘Follow-me’ format. An additional number can be programmed for use in conjunction with the RP callback feature.

  • Page 5: Remote Programming

    1.4: Remote Programming Electronics Line’s remote programming software enables programming and operation from a PC. The software provides a comprehensive interface to the Penta control panel, facilitating and cutting down the time taken in programming the system. RP access is gained using a four digit code programmed at address 57.

  • Page 6: Chapter Two: Installation

    Chapter Two: Installation 2.1: Parts and Options Standard Parts Penta household burglary alarm control panel 3104 LED keypad 2.2KΩ ¼W resistors 6 x ¼ screws Mounting studs PCB support Installation manual User manual Optional Parts Additional 3104 LED keypad 3601 voice message module...

  • Page 7: Wiring Diagram

    2.2: Wiring Diagram...

  • Page 8: Terminal Connections

    2.3: Terminal Connections 15-16.5Vac Input Terminals 1 & 2: Connect a 15Vac transformer rated at 22-30VA, using 18 AWG wire. Auxiliary Power Output Terminals 3(+), 4(-): The auxiliary power output connections supply power to keypads and peripheral units such as detectors and other powered sensors. Keypad Data Bus Connections Terminals 5 &...

  • Page 9: Mounting The Keypad

    Switch Figure 2.4: 3104 LED Keypad (cover removed) Up to 3 LED keypads can be connected to the Penta control panel. To mount the keypad: 1. Separate the front and back cover of the keypad by pressing the locking tabs, situated at the bottom of the keypad, with a small flathead screwdriver.

  • Page 10: Turning On The System

    Once all of the systems components are properly connected to their destination terminals, the Penta is ready to be turned on. To avoid the risk of electrical shock or damage to the control panel, make sure that both the AC supply and the battery are connected properly before plugging in the system.

  • Page 11: Chapter Three: System Operation

    Chapter Three: System Operation 3.1: General All operation and programming of the Penta can be performed using any one of the three LED keypads that can be installed with each system. This section offers a complete explanation of the keypad functions and of the LED display, incorporating a summary of command codes used in system operation.

  • Page 12: Command Codes

    Enter a valid user code; the keypad beeps until the end of the exit delay. Quick Arming This feature allows the Penta to be armed without a valid user code. Quick arming the system transmits an “Armed by User 1” message to the central station.

  • Page 13: Distress Keys

    Note: It is not recommended to use this feature with an external keypad. Disarming The Penta can be disarmed by entering a valid user code during the entry delay. If an error is made entering the code, press ‘#’ and enter the code again. When the code is accepted the Armed LED and the pulsed delay tone are turned off.

  • Page 14: User Codes

    3.6: User Codes The Penta is capable of maintaining four user codes, a duress code and an installer code. Each of these codes are four digits long. Of the four user codes, only User Code 1 (default 1111) has authorization to modify other user codes and the duress code.

  • Page 15: Zone Bypassing/Unbypassing

    3.7: Zone Bypassing/Unbypassing The Penta offers the user the ability to bypass zones. When a zone is bypassed, it is ignored by the system and will not generate an alarm when tripped. To bypass a zone: Press Q, 1. Enter a valid user code; the System LED flashes and the LEDs of any currently bypassed zones light up.

  • Page 16: Additional Operations

    3.9: Additional Operations Bell Cancel To cancel the bell: • Enter a valid user code or turn the keyswitch as if disarming the system. Bell/LED Test To perform a bell/LED test: • Press Q, 4, 1; the siren is sounded and all LEDs on the keypad are lit for a period of two seconds.

  • Page 17: Chapter Four: Programming

    The options for each address are listed in section 4.3: Programming Parameters. All of the programming parameters are stored in the Penta’s non-volatile EEPROM memory which stores the data in the event that power is disconnected. Before programming directly after installing the system, restore the default parameters as explained in 2.5: Turning on the System.

  • Page 18: Programming Parameters

    4.3: Programming Parameters The following section lists the Penta’s programming parameters which are used to configure the system. For a listing of the default parameters please contact your local dealer. Address 00: Communication Attempts The control panel’s attempts to communicate with the central station are organized in rounds.
  • Page 19 Address 02: Communication Options This address consists of the various options used in communication and/or remote programming. Enter five digits according to the following. First Digit: Protocol 0 - 20pps 4/2 no parity 1 - Follow Me 2 - Contact ID 3 - Voice Message (3601) 4 - 10pps 3/1 no parity Second Digit: RP Access Type...
  • Page 20 Address 07: Entry Delay Time The entry delay timer determines the amount of time the user has to disarm the system before an alarm is activated. The entry delay is only initiated if the premises are entered through a zone defined as ‘perimeter with delay’. Enter a hexadecimal value between 1 and 255 seconds at this address using the hexadecimal conversion chart in Appendix A.
  • Page 21 Address 16: [P] Key Alarm* Address 17: [F] Key Alarm* Address 18: [E] Key Alarm* Address 19: Zone 1 Restore Address 20: Zone 2 Restore Address 21: Zone 3 Restore Address 22: Zone 4 Restore Address 23: Tamper Zone Restore Address 24: [P] Key Alarm restore Address 25: [F] Key Alarm restore Address 26: [E] Key Alarm restore...
  • Page 22 Address 43: Keypad Trouble Restore Address 44: Bell Cancel Address 45: Periodic Test Address 46: Bypass Zone 1 Address 47: Bypass Zone 2 Address 48: Bypass Zone 3 Address 49: Bypass Zone 4 Address 50: Unbypass Zone 1 Address 51: Unbypass Zone 2 Address 52: Unbypass Zone 3 Address 53: Unbypass Zone 4 Telephone numbers...

  • Page 23: Periodic Test Timer Reset

    Address 59: Installer Code The installer code is a 4-digit code which grants access to programming mode. The default for this code (1234) should be changed immediately after installing the system. Note: Do not enter Hex digits. 4.4: Periodic Test Timer Reset The periodic test event code (address 45) is sent to the central station once every 24 hours.

  • Page 24: Appendix A: Hexadecimal Conversion Chart

    Appendix A: Hexadecimal Conversion Chart The following is a decimal to hexadecimal conversion chart to be used as an aid in programming: -24-...

  • Page 25: Appendix B: Glossary Of Terms

    Appendix B: Glossary of Terms 24hr Zone A zone which is always active regardless of whether the system is armed or disarmed. Opening a 24hr zone always generates an alarm. AC Loss The disruption of AC power. In the event of AC loss, the panel waits five minutes before sending an event message.
  • Page 26 See Delay Entry Delay Event Code The two-digit code transmitted to the central station to indicate that an event has occurred. Event Log The two event logs record and display events the system has undergone since the last arming. Exit Delay See Delay Follow-Me A method of monitoring the system without connecting to a central station...
  • Page 27 Ready The state in which all zones are closed and the system is ready to be armed. Remote The software developed by Electronics Line used for programming the Programmer system using a PC from a remote location or on-site. Restore The restoral of a trouble condition to its normal state.

  • Page 28: Index

    Index 24hr Zone ..........4, 19 F Key ............13 Account Number..........22 Fast Loop Perimeter Zone ......4 Additional Operations........16 Fire Key ............13 Answering Machine Override......5 Follow-me ............4 Arming ............12 General Description....... 4, 5 Forced .............12 Forced Arming..........12 Immediate ..........13 Fuse Replacement ........
  • Page 29 Power Output..........3 Telephone Numbers ........ 4, 22 Programmable Output........20 Telephone Options ........19 Programming ..........17 Terminal Connections........8 Duress Code ...........14 Test Guide............17 Bell ............16 Parameters ........17, 18 Walk............16 User Codes ..........14 Trouble Indication ........20 Quick Arming..........12 Turning on the System ........
  • Page 30 ELECTRONICS LINE (E.L.) LTD. AND ITS SUBSIDIARIES - LIMITED WARRANTY ELECTRONICS LINE (E. L.) LTD. AND ITS SUBSIDIARIES (hereafter “E.L.”) warrants its products to be free from manufacturing defects in materials and workmanship for 2 years following the date of sale. E.L. will, within said period, at its option and in accordance with the terms of this Limited Warranty, repair or replace any product failing to operate correctly without charge to the original purchaser or user.
  • Page 31 Penta - Default Values COMMUNICATION ATTEMPTS __,__ (00) (3 communication rounds, 5 dialing attempts in each round ) (01) SYSTEM PARAMETERS ____,____,____,____,____ Keypads One Keypad Keyswitch Function Latching Tamper Zone Definition Tamper Zone E Key Alarm Silent Alarm P Key Alarm...
  • Page 32 Penta - Programming Worksheet (00) COMMUNICATION ATTEMPTS ____,____ Communication Rounds 1-F (F=unlimited rounds) Dialing Attempts (01) SYSTEM PARAMETERS First Digit: Keypads ____,____,____,____,____ 0 - No Keypads 1 - One Keypad 2 - Two Keypads 3 - Three Keypads Second Digit: Keyswitch Function...
  • Page 33 EVENT CODES __,__ __,__ (11) Alarm from Zone 1 (33) Disarmed (User 3) __,__ __,__ (12) Alarm from Zone 2 (34) Disarmed (User 4) __,__ __,__ (13) Alarm from Zone 3 (35) Disarmed (Duress) __,__ __,__ (14) Alarm from Zone 4 (36) Low Battery __,__...
