AXP-200
Exploded View
Important! Before proceeding with installation, please check for the most
up-to-date instructions at www.thermalright.com
Heatsink Body
Anchoring Mount
1
Intel 775/115x/1366
M3 L17 Screw
TY-14013 Fan
M3 L6 Screw
Mounting Plate
Screw Nut
Intel Washer (small)
Metal Back Plate
M3 L10 Screw
