About the MultiDrive

© 2018 Autoslide Pty Ltd
The MultiDrive is an automatic door opening system for
residential and light-use commercial sliding doors.
Once installed, the MultiDrive mechanism is hidden discretely
behind an aluminum cover which blends in with the sliding door
frame. This cover comes in a mill finish and will need to be powder
coated to match the door and/or frame.
The MultiDrive can be retro-fitted to any framed sliding door,
including bi-parting doors (Figure 1) and non-bi-parting doors
(Figure 2).
Figure 1: Bi-parting doors with the MultiDrive.
a)
c)
Figure 2: Non-bi-parting doors with the MultiDrive: a) single left-
sliding door, b) telescopic left-sliding door, c) single right-sliding
door, and d) telescopic right-sliding door.
Warnings
•
Any manual lock on the sliding door should be removed or
deactivated, otherwise the MultiDrive may be damaged if
activated while the lock is closed.
•
The MultiDrive should not be used in high-traffic
environments such as large office building entrances or big-
box stores.
•
The MultiDrive may be used in light commercial
environments. Speak with an authorized Autoslide Pty
representative about your application prior to purchase.
b)
d)
