- Page 1 ELSIE DAYBED TRUNDLE ASSEMBLY INSTRUCTION Date: 2013-Nov.-04 Rev: www.pbteen.com Page 1 of 5...
- Page 2 Important safety instructions: • Please read all instructions carefully before assembling this Trundle. • For your safety, assembly by two or more adults is strongly recommended. • Keep these instructions for future use. • Use only vendor-supplied hardware to assembly this item. Using unauthorized hardware could jeopardize the structural integrity of the item.
- Page 3 L- Small Pan Head Screw M - Castor TOOLS REQUIRED (but not included): Phillips Head Screwdriver 8x12mm 50x50x65mm 24 pcs 6 pcs Assembly Instruction Steps: Place the 2 Side Bottom Panels (D) with the pre-drilled holes facing up. Slot the protruding edges of the Side Bottom Panels (D) into the sunken edges of the Middle Bottom Board (E), as seen in the illustration below.
- Page 4 Fasten the 6 Casters (M) to the Side Bottom Panels (D) and secure with 6 Short Pan Head Screws 17x8mm (L). Make sure to use the pre-drilled holes of the Side Bottom Boards (D) as a guide. 24 x 6. Turn the assembled piece to the upright position. Attach the Front Panel (A) and Back Panel (B) to the Side Bottom Panels by aligning the pre-fixed wooden dowels at the end of Bottom Board Support (F), to the pre-drilled holes on the Front Panel (A) and Back Panel (B), as seen in the illustration below.
- Page 5 HARDWARE LIST HARDWARE LIST PART LIST PART LIST Allen key ( 1 pc ) Bolt (1/4" x 38mm) ( 8 pcs ) Bolt (1/4" x 25mm) (28 pcs ) Spring washer (1/4") (36 pcs ) Flat washer (1/4") (36 pcs ) Half - moon metal block ( 8 pcs ) Plastic cap...
