FullHD Wireless
HD Set for HDMI

Part 1 Package Content and Connectors

Quick Installation Guide
Rear View of Transmitter

Part 2 Quick Installation Description

Hardware Installation

Transmitter Connections:

Connect to PC via HDMI
Connect PC to WHD030-V2 TX
(transmitter) by „HDMI IN" port.
Connect the Mini-USB cable to the
Transmitter and then to your PC.

Receiver Connections:

Connect to HDTV via HDMI
Connect the „HDMI OUT" port of the
WHD030-V2 RX (receiver) to the „HDMI
IN" port of the HDTV with an HDMI cable.
Connect the power adapter to the
receiver.
Mini-USB
HDMI Cable x 1
Power Adapter x2
POWER IN
HDMI IN
DC IN
HDMI OUT
Quick Installation Guide
Receiver (RX)
USB Cable
Anchors x2
(for Transmitter)
Screws x2
Rear View of Receiver
WHD030-V2
Transmitter (TX)
User´s Manual
Laptop
HDTV
