- Page 1 MXWALL-UHD 8×8 Ultra HD (4K@60Hz) Video Wall Customize 8 inputs and 8 outputs through IP Control, RS-232 command capabilities, and a Windows GUI Installation Manual MADE IN USA...
- Page 2 Introduction......................Front Panel Control....................Rear Panel......................... RS232 Control......................RS232 Connector....................MXWALL-UHD User Guide .................. Connecting with the Web Page............5.1.1 Connecting with the Web Page: Video Matrix....5.1.2 Connecting with the Web Page: TV Wall......5.1.3 Connecting with the Web Page: Configuration.....
- Page 3 MXWALL-UHD is a high-performance seamless UHD matrix switcher with 8x HDMI inputs and 8x HDMI outputs. Audio extract or insert can also be enabled on this device. IR matrix routing on this video matrix is followed with video routing. MXWALL-UHD support one or more video wall with RS232 command MXWALL-UHD key features support: •...
- Page 4 • LAN(10M/100M), RS232 are for the MXWALL-UHD software. Analog • IR IN and IR OUT IR IN/OUT is for remote control routing, and follow the video routing. For example, if input HDMI m is routed to output HDMI n1 and n2 ports, then IR IN n1 and n2 ports will be routed to IR OUT m port.
- Page 5 RS232-2 and IR-EXT ports are reserved for future development The MXWALL-UHD can be connected through either the web or our provided software. The web connection will require the device to be on the same network as the PC that will control it.
- Page 6 By using the web page, the user is provided with two different options on how to configure their video settings. Video Matrix: This is the home page that the user starts in. Video Matrix allows the user to quickly select each individual input and output. TV Wall: This page allows the user to create “stitches”...
- Page 7 On the top left of the page there is a purple button with three lines, clicking this will open up the Configuration page. Please note that the Matrix Switch page only displays the “Open Settings” option. For the TV Wall, the user is provided with the option to change matrix presets and can also set the resolution.
- Page 8 Upon launching the MXWALL-UHD software, the user will be prompted to sign in. On first boot up, the Administrator username and password will already be provided. The user may add additional users with or without administrative privileges within the Users tab.
- Page 9 This setup is similar to using the network on the software to connect. Select “Use serial port connection” in the Connect tab and change the Serial port name to the appropriate COM port connection and set the Baud rate to 9600. Once all of these settings are selected, click OK and the software will search for the matrix using RS232.
- Page 10 PINK BOX is an easy way to quickly close out all existing stitches. There are several main tabs within the MXWALL-UHD software. 1. Connections – Opening this menu will bring up a window that shows all currently connected devices, showing their connection type. Here the user can easily remove a connected device by highlighting the connection and clicking REMOVE.
- Page 11 2. Connect – Please refer to Section 5.2.2 and 5.2.3 3. Settings – Opening this menu will bring up a window that provides the user with the option to change the matrix layout as well as the resolution. To change the matrix layout simply add or remove the number of rows or columns.
- Page 12 4. Users – Please refer to Section 5.2 and 5.2.1 5. Scheduler – Opening this menu will bring up the Scheduler window that allows the user to set date specific schedules for saved layouts to automatically set up. Please note that because of this, the user is required to register layouts in the general page of the software first before the scheduler can be used.
- Page 13 6. Close All – This will close all current stitching in the matrix. ELECTRICAL PARAMETER Interface HDMI-A HDMI /DP /VGA Version HDMI2.0,HDCP2.2 Bandwidth 18Gbps Input 800x600@60Hz,1024x768@60Hz, 1280x768@60Hz, 1280x800@60Hz,1280x1024@60Hz,1360x768@60Hz, 1366x768@60Hz,1400x1050@60Hz,1440x900@60Hz, 1600x1200@60Hz,1680x1050@60Hz, 1920x1200@60Hz, 480p,576p,720p,1920x1080i, 1920x1080p,3840x2160@24Hz/25Hz/30Hz/50Hz/60Hz, 4096x2160@24Hz/25Hz/30Hz/50Hz/60Hz. Output 3840x2160@60Hz, 3840x2160@50Hz, 3840x2160@30Hz, 3840x2160@25Hz, 1920x1200@60Hz,1920x1080@60Hz 1920x1080@50Hz,1600x1200@60Hz, 1400x1050@60Hz,1366x768@60Hz, 1360x768@60Hz, 1280x1024@60Hz,...
- Page 14 ： 1,no parity checking Ethernet IE10.0+,HTML5 POWER Max Consumption 100W, 110-240VAC MATRIX MECHANICAL DIMENSIONS 430(L)X300(W)X44 (H) Size(mm) Weight Operating temperature 0 to 40°C Storage temperature -20 to 70°C Permissible humidity 10%-50% ITEM QUANTITY MXWALL-UHD unit MXWALL-UHD User Manual AC Power Cord...
- Page 15 NOTICE The information contained in this document is subject to change without notice. SmartAVI makes no warranty of any kind with regard to this material, including but not limited to, implied warranties of merchantability and fitness for any particular purpose. SmartAVI will not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material.
