- Page 1 MXwall-uhd 16x16 seamless ultra high definition matrix USER MANUAL Designed and Manufactured in the USA 1-800-284-2131 www.smartavi.com...
-
Page 2: Table Of Contents
OVERVIEW TECHNICAL SPECIFICATIONS_________________________________________________________________ WHAT’S IN THE BOX?________________________________________________________________________ FRONT AND BACK___________________________________________________________________________ INTRODUCTION_____________________________________________________________________________ FRONT PANEL CONTROL_____________________________________________________________________ REAR PANEL__________________________________________________________________________________ RS232 CONTROL____________________________________________________________________________ HARDWARE INSTALLATION_________________________________________________________________ MXWALL-UHD USER GUIDE_________________________________________________________________ 8-13 AVAILABLE CONFIGURATIONS______________________________________________________________ TROUBLESHOOTING_________________________________________________________________________ TECHNICAL SUPPORT________________________________________________________________________ LIMITED WARRANTY STATEMENT____________________________________________________________ 16x16 Ultra HD (4K@60Hz) Video Wall... -
Page 3: Technical Specifications
Technical Specifications VIDEO Video Amplifier Bandwidth 18 Gbps Input Video Signal Video (TMDS) 0.4~1.0Vpp Input DDC Signal 5 volts Compliances HDMI 2.0, HDCP 2.2 Input Resolutions 3840 x 2160 @ 24 Hz / 25 Hz / 30 Hz / 50 Hz / 60 Hz Output Resolutions 3840 x 2160 @ 24 Hz / 25 Hz / 30 Hz / 50 Hz / 60 Hz;... -
Page 4: What's In The Box
What’s in the box? PART NO. Q-TY DESCRIPTION MXwall-UHD-S 16x16 4K/60Hz Video Wall Processor and Matrix Switch CCPWR06 Power supply cord User Manual MXwall-UHD FRONT MXwall-UHD BACK 16x16 Ultra HD (4K@60Hz) Video Wall... -
Page 5: Introduction
INTRoduction MXwall-UHD is a high-performance seamless UHD matrix switcher with 16 HDMI inputs and 16 HDMI outputs. Audio extraction or insertion can also be enabled on this device. IR matrix routing on this video matrix is followed with video routing. -
Page 6: Rear Panel
REAR PANEL • LAN(10M/100M), RS232 are for the MXWall-UHD software. RS232 control RS232 CONNECTOR • RS-232 control, baud rate 115200, DB9 connector. • Port RS232-1 uses a DB9 female connector. The user will need to use the corresponding direct/ straight RS232 cable. The pin layout is shown as follows: •... -
Page 7: Hardware Installation
4. Optionally connect an RS-232 cable from a PC to the RS-232 port on the unit for additional control. 5. Optionally connect an Ethernet cable to the MXwall-UHD for additional control. 6. Turn on the MXwall-UHD and wait a few seconds for the unit to initialize. a r t... -
Page 8: Mxwall-Uhd User Guide
MXwall-uhd user guide (continued) CONNECTING WITH THE SOFTWARE Upon launching the MXwall-UHD software, the user will be prompted to sign in. On first boot up, the Administrator username and password will already be provided. The user may add additional users with or without administrative privileges within the Users tab. - Page 9 MXwall-uhd user guide (continued) Ethernet connection The user can search for the MXwall-UHD using the Connect tab in the MXwall-UHD software as long as the device and PC are within the same network. After opening Connect, select “Use network connection” and click on “Start” next to Search devices. Select the connected Matrix to add to the main page and then click OK.
- Page 10 Within the GREEN BOX shown below, there are three MXwall-UHD devices connected. The blue highlighted tab (192.168.1.113) will show which device is currently being controlled for interaction. PURPLE BOX b. On the left side in the where input 1-8 are shown, the user can drag these input boxes to the desired output.
- Page 11 MXwall-uhd user guide (continued) NAVIGATION MXWALL-UHD There are several main tabs within the MXwall-UHD software. 1. Connections – Opening this menu will bring up a window that shows all currently connected devices, showing their connection type. Here the user can easily remove a connected device by highlighting the connection and clicking “REMOVE”.
- Page 12 MXwall-uhd user guide (continued) 4. Please refer to account creation and modification on page 8. 5. Scheduler – Opening this menu will bring up the Scheduler window that allows the user to set date specific schedules for saved layouts to automatically set up. Please note that because of this, the user is required to register layouts in the general page of the software first before the scheduler can be used.
- Page 13 MXwall-uhd user guide (continued) 6. Close All – This will close all current stitching in the matrix. 16x16 Ultra HD (4K@60Hz) Video Wall...
-
Page 14: Available Configurations
It is easy to create different configurations or modes that are easy to navigate through with the MXwall-UHD. There are endless possibilities. Creating and switching between display modes is simple. The touchscreen front panel, on-screen-display, RS-232, and TCP/IP can be used to switch between modes at will. -
Page 15: Troubleshooting
Troubleshooting No Power • Make sure that the power adapter is securely connected to the power connector of the unit. • Check the output voltage of the power supply and make sure that the voltage value is around 12VDC. • Replace the power supply. No Video •... -
Page 16: Limited Warranty Statement
Limited warranty statement A. Extent of limited warranty SmartAVI, Inc. warrants to the end-user customers that the SmartAVI product specified above will be free from defects in materials and workmanship for the duration of 1 year, which duration begins on the date of purchase by the customer. Customer is responsible for maintaining proof of date of purchase. - Page 17 NOTICE The information contained in this document is subject to change without notice. SmartAVI makes no warranty of any kind with regard to this material, including but not limited to, implied warranties of merchantability and fitness for particular purpose. SmartAVI will not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material.
