SMART-AVI HDR-4X2-Pro Quick Start Manual

4k/2k resolution 4x2 hdmi matrix switch

Advertisement

Quick Links

What's in the Box?
PART NO.
QTY
DESCRIPTION
HDR-4X2-Pro
1
HDR-4X2-Pro Router
Power Supply
1
PS5VDC2A
Technical Specifications
VIDEO
Format
HDMI 1.3b [Deep Color, xvYcc color space supported]
DVI Compliance
Single-link DVI-D 1.1
HDCP Compliance
1.0/1.1
Video Bandwidth
Single-link 340MHz [10.2Gbps]
Resolution
480i,480p,720i,720p,1080i,1080p
Input Interface
(4) HDMI[7.1ch audio & video]
Output Interface
(2) HDMI[7.1ch audio & video]
Connector
Type A[19-pin female]
Maximum Distance
25 ft.
CONTROL
Front Panel
Tact Switch
IR
Via Remote Control with IR Type 3
OTHER
Power
External 100-240 VAC/5VDC2A @10W
Dimensions
6.625"W x 1"H x 2.875"D
Weight
0.8 lbs.
Approvals
UL, CE, ROHS Compliant
Operating Temp.
32-131°F (0-55 °C)
Storage Temp.
-4-185 °F (-20-85 °C)
Humidity
Up to 95%
© Copyright 2011 Smart-AVI, All Rights Reserved
NOTICE
T h e i n f o r m a t i o n c o n t a i n e d i n t h i s d o c u m e n t
is subject to change without notice. Smart-AVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for any particular purpose.
Smart-AVI will not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance or use of this material.
No part of this document may be photocopied, reproduced or
translated into another language without prior written consent
from Smart-AVI.
For more information, visit www.smartavi.com.
Rack Mountable Option
Our SmartRack is the perfect solution to allow
virtually all SmartAVI devices to be custom mounted
in a standard 19" server rack. The SmartRack is fully
adjustable and can secure/organize several devices.
SmartAVI, Inc. / Twitter: smartavi
11651 Vanowen St. North Hollywood, CA 91605
Tel: (818) 503-6200 Fax: (818) 503-6208
http://www.SmartAVI.com
HDR-4X2-Pro
4K/2K Resolution 4x2 HDMI
Matrix Switch
Delivers 4K/2K resolution while
switching four singals
between two displays.
Quick-Start Guide
www.smartavi.com
