OPTIGA™ Trust E
Security Shield2Go
Quick Start
V1.0.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the OPTIGA Trust E Security Shield2Go and is the answer not in the manual?

Questions and answers

Related Manuals for Infineon OPTIGA Trust E Security Shield2Go

Summary of Contents for Infineon OPTIGA Trust E Security Shield2Go

  • Page 1 OPTIGA™ Trust E Security Shield2Go Quick Start V1.0.0...
  • Page 2 3 kBytes user memory. The communication interface is I2C and the device supports ECC 256 bit and SHA-256. Link to Datasheet Product Page 2018-07-17 Copyright © Infineon Technologies AG 2018. All rights reserved.
  • Page 3 Sales Name S2Go Security OPTIGA E and OPN • S2GOSECURITYOPTIGAETOBO1 Ensure that no voltage applied to any of the pins exceeds the absolute maximum rating of VCC + 0.3 V Link to Board Page 2018-07-17 Copyright © Infineon Technologies AG 2018. All rights reserved.
  • Page 4 Evaluation Board PCB Details 2018-07-17 Copyright © Infineon Technologies AG 2018. All rights reserved.

  • Page 5: Evaluation Board Schematic

    Evaluation Board Schematic OPTIGA™ Trust E Green area: circuit if head is broken off 2018-07-17 Copyright © Infineon Technologies AG 2018. All rights reserved.
  • Page 6 Extended information about the Arduino environment. Click here • How to import libraries? Click here • How to install additional boards? Click here • Problems related to Arduino? Click here for troubleshooting • 2018-07-17 Copyright © Infineon Technologies AG 2018. All rights reserved.
  • Page 7 (see next slide for further instructions) Additional notes for • installation can be found in the GitHub repository, e.g. if the library manager is not used https://github.com/Infineon/OPTIGA-Trust-E-Security-Controller 2018-07-17 Copyright © Infineon Technologies AG 2018. All rights reserved.
  • Page 8 As shown in the picture, please choose the respective library and install it • Regularly check your installed libraries for updates • In case of problems, please visit also our GitHub repository and open an issue • to get further help https://github.com/Infineon/OPTIGA-Trust-E-Security-Controller 2018-07-17 Copyright © Infineon Technologies AG 2018. All rights reserved.
  • Page 9 Connect the stacked boards to the PC and press the Upload button • Select the related COM port from Tools – Port and open the serial monitor with • the set baud rate (see sketch/code with Serial.begin(<BAUDRATE>);) https://github.com/Infineon/XMC-for-Arduino https://github.com/Infineon/OPTIGA-Trust-E-Security-Controller 2018-07-17 Copyright © Infineon Technologies AG 2018. All rights reserved.
  • Page 10 The input voltage on any pin should • not exceed VCC+0.3 V Third party boards with 5 V logic, e.g. • the Arduino Uno, can be connected to the OPTIGA™ Trust E Security Shield2Go directly Possible 2018-07-17 Copyright © Infineon Technologies AG 2018. All rights reserved.
