ProtoNode Startup Guide

Appendix C Reference

Appendix C.1. Specifications

ProtoNode RER
One 6-pin Phoenix connector, one RS-485 +/-
ground port, power +/- frame ground port
Electrical
One 3-pin RS-485 Phoenix connector, one RS-
Connections
485 +/- ground port
One Ethernet-10/100 Ethernet port
CE (EN55022;EN55024; EN60950), UL916, FCC Class A Part 15, DNP3 Conformance Tested,
Approvals OPC Self-tested for Compliance, RoHS Compliant, CSA 205 Approved
BTL Marked
Power
Multi-mode power adapter: 9 - 30VDC or 12 - 24VAC
Requirements
Physical
11.5 cm L x 8.2 cm W x 4.0 cm H (4.5 x 3.2 x 1.6 in.)
Dimensions
Weight 0.2 kg (0.4 lbs.)
Operating
-40°C to 75°C (-40°F to167°F)
Temperature
Surge Suppression EN61000-4-2 ESD EN61000-4-3 EMC EN61000-4-4 EFT
Humidity 5 - 90% RH (non-condensing)
(Specifications subject to change without notice)
FPC-N34
FPC-N35
FPC-N36
ProtoNode
FPC-N37
FPC-N38
FPC-N39
1 Tx/Rx/GND
2 +/-/Frame Ground
3 TBD
4 10/100 BaseT
5 FTT 10
ProtoCessor 1991 Tarob Court Milpitas, California 95035 USA Web: www.protocessor.com
Tel: (408) 964 4444 Fax: (408) 262-2269 Toll Free: 888-509-1970 X141 email: support@protocessor.com
1 2
RS-232 RS-485
2
1
1
1 1
1
ProtoNode LER
One 6-pin Phoenix connector, one RS-485 +/-
ground port, power +/- frame ground port
One Ethernet 10/100 BaseT port
One FTT-10 LonWorks port
LonMark Certified
Interface Connections
3
RS-422 Ethernet
1
1
Page 18 of 25
4 5
LonWorks
1
1 1
1
1 1
1
1 1
