8. Status Visualization

The following icons are visualized on the chargers screen*, once the
energy meter has been detected.
Energy meter detected but not configured. Follow the chapter 7
of this manual.
Power Boost is configured but not limiting the charging power.
Power Boost is limiting the charging current. The current
available for charging the car is lower than the maximum power
set by the user.
In queue by Power Boost. The available power is not enough for
charging the EV (lower than 6 A).
Error in the communication with the energy meter.
*Doesn't apply for Copper SB nor Pulsar Plus.
