Valor L1 Series Nstallation Instructions

1500-1600NGK, 1500PGK, 1600PGK
This appliance is certifi ed for use from 0–4500 feet. For
altitudes above 4500 feet, see local codes.
Kit Contents
1 Pilot injector
1 Main burner elbow injector
1 Set of conversion labels
1 Air shutter (NG only)
1 bypass screw
1 burner injector gasket
Tools Required
• Wrenches, to disconnect gas line
• Phillips (+) screwdriver, to remove burner module &
pilot shield
• Small (jewelers size) fl at blade screwdriver, to set
pressure
• Small fl at blade screwdriver, to release pressure tap
on valve
• Needle nose pliers, to remove by-pass screw
• Hex (Allen) wrench, 4 mm or 5/32", to remove pilot
injector
• Manometer, to set manifold at the valve
Specifi cations
Models
Gas
Altitude (Ft.)*
Input Maximum (Btu/h)
Input Minimum (Btu/h)
Manifold Pressure (in w.c.)
Minimum Supply Pressure
(in w.c.)
Maximum Supply Pressure
(in w.c.)
Main Burner Injector
Marking
Pilot Injector Marking
Min. Rate By-Pass Screw
4002880-04
© Copyright Miles Industries Ltd., 2017
L1 Series
Gas Conversion Kit
Use with Valor Models 1500 and 1600 Heater ONLY
Installation Instructions
1500NG 1500LPG 1600LPG
1600NG
Natural Propane
0-4,500 feet*
30,000 28,000
18,000 18,500
4.0 9.5
5.0 11.0
10.0 14.0
850 300
51 30
220 160
This conversion kit shall be installed by a
qualifi ed service agency in accordance with
the manufacturer's instructions and all appli-
cable codes and requirements of the authority
having jurisdiction. If the information in these
instructions is not followed exactly, a fi re, ex-
plosion or production of carbon monoxide may
result causing property damage, personal in-
jury or loss of life. The qualifi ed service agency
is responsible for the proper installation of this
kit. The installation is not proper and complete
until the operation of the converted appliance
is checked as specifi ed in the manufacturer's
instructions supplied with the kit.
Use this manual in conjunction with the instal-
lation manual supplied with the appliance.
General notes regarding conversion
The conversion may be done before or after the
Propane
appliance is installed into the cavity. Ideally before
the wall fi nish is applied, otherwise the burner
26,000
module must be removed. The gas must be
18,500
connected in order to set the manifold pressure.
10.0
Prepare the appliance
11
1. If the fi replace is already installed, remove the
side hinged doors, plinth, window, fuel bed,
14
platform, and platform middle supports.
2. Disconnect the gas inlet pipe from the inlet
260
elbow fi tting on the valve.
30
160
