Vista NCD635CKe Installation Instructions

This camera range is designed for use in general purpose CCTV applications and has no other purpose. Only operate your
camera between the temperatures of -10
Cameras must only be used in clean, dry, dust-free environments unless housed in suitable protective housings to IP65 or better.
In order to avoid damaging the camera note the following points:
1. Installation and servicing is only to be carried out by suitably qualified and experienced personnel.
2. Only power cameras from the power supply provided.
3. Do not touch the image-surface of the sensor. If the sensor is accidentally touched, only clean it using isopropanol.
4. Do not expose the camera sensor to very bright light over a long period of time as this may cause damage to the CCD.
The camera and lens set-up must be correct to avoid continual over-exposure to bright light.
5. For outdoor use, an appropriate protective housing conforming to IP65, UL50 or better must be used.
This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may
be required to take adequate measures.
This product is intended solely for use in general CCTV applications.
The product must be installed and maintained in accordance with good installation practice to enable the product to function as
intended and to prevent problems. Refer to Norbain SD Limited for installation guidance.
The manufacturer declares that the equipment supplied with this manual is compliant with EMC directive 89/336/EEC, CE Marking
Directive 93/68/EEC. Conforming to BSEN55022:1998 Information technology equipment CLASS A, BSEN 50130-4:1996 Alarm
systems-Part 4, and all amendments.
Keep your packaging for use if the product is to be stored for an extended period or needs to be returned for any reason. The
packaging should contain:
• A Vista Kit Camera with an integrated DC lens
• 12V DC power supply
• 2 BNC to coaxial connectors
Check the product code on the serial number label. If you have an incorrect item or it is damaged then inform the suppliers and
carriers immediately. If this is the case then do not attempt to use the equipment.
The diagram below shows the location and function of the controls and switches.
C and +50 C. Do not operate your camera outside its specified power supply range.
O O
• Camera mounting bracket
• Two fixing screws
• Installation instructions
Vista Varifocal Kit Cameras

ELECTROMAGNETIC COMPATIBILITY (EMC)

MANUFACTURER’S DECLARATION OF CONFORMANCE
Installation Instructions

PRODUCT SAFETY

UNPACKING

CONTROLS AND SWITCHES
