CHALLENGER
Module
Kit Part Number: CCCON01 (CC85, CC105,
CC125, CC85s -CC125s)
CCCON02 (CC150)
Parts List
-
Challenger Control Display Module
Recommended tools:
-
Phillips Screw Driver.
W RNING
Indicates a potentially hazardous situation
which, if ignored, can result in serious
injury or substantial property damage.
W RNING
For your safety, turn off electrical power
supply at service panel before proceeding to
avoid possible electrical shock hazard.
Failure to do so can cause severe personal
injury or death.
NOTI E
Note current control parameter settings
prior to any control replacement.
Control Display
Replacement Kit
Challenger Control
NOTI E
Indicates special instructions on installa-
tion, operation or maintenance, which are
important to equipment but not related to
personal injury hazards.
W RNING
Failure to follow instructions below can result
in severe personal injury or damage if ignored.
•
Instructions are for a qualified installer/ ser-
vice technician.
•
Read all instructions before proceeding.
•
Follow instructions in proper order.
