TriangleTube PRESTIGE TriMax PTRKIT205 Quick Start Manual

PRESTIGE TriMax Control
and/or Display Module Replacement
Kit Part Number:
- PTRKIT205 -
TriMax Control Module
(PT 60/110, 175, PTE 110)
-
- PTRKIT206 TriMax Control Module
(PT250/399)
PTRKIT207 -
- TriMax Display Module
Parts List (Fig.1)
1 - Control Module (PTRKIT205) - Item 1
2 - Display Module (PTRKIT207) - Item 2
Recommended Tools:
- Phillips Screwdriver
W RNING
Indicates a potentially hazardous situation
which, if ignored, can result in serious
injury or substantial property damage.
W RNING
For your safety, turn off electrical power
supply at service panel before proceeding to
avoid possible electrical shock hazard.
Failure to do so can cause severe personal
injury or death.
W RNING
For your safety, the boiler may be extremely
hot. Ensure the boiler has properly cooled
prior to servicing. Failure to do so can cause
severe personal injury.
Fig. 1: PRESTIGE Solo Control
NOTI E
Indicates special instructions on installa-
tion, operation or maintenance, which are
important to equipment but not related to
personal injury hazards.
W RNING
Failure to follow instructions below can
result in severe personal injury or damage if
ignored.
• Instructions are for a qualified installer/
service technician.
• Read all instructions before proceeding.
• Follow instructions in proper order.
NOTI E
These part kits PTRKIT205, PTRKIT206
and PTRKIT207 can only be used on
Prestige Boilers with serial numbers begin-
ning with PT.
1
2
1
