Product Declassification and Security
Memory Clearing, Sanitization and/or Removal Procedures
This section explains how to clear, sanitize, and remove memory from your instrument for all memory types.
<Memory type>
Description and
purpose
Size
Memory clearing
Memory sanitization
Memory removal
Write protecting
Memory validation
Remarks
Description and
purpose
Size
Memory clearing
Memory sanitization
Memory removal
Write protecting
Memory validation
Remarks
Description and
purpose
Size
Memory clearing
Memory sanitization
Memory removal
Write protecting
Memory validation
Remarks
Main Memory for Windows Operating system memory
Windows XP: 2 GB, Windows 7: 4 GB, Windows 10: 4 GB
Power rebooting. This is a volatile memory.
Power rebooting. This is a volatile memory.
This memory cannot be removed without damaging the instrument
N/A
N/A
Media Storage (Hard Disk Drive/Solid State Drive)
Windows XP/HDD:160 GB/ 320 GB, Windows 7/SSD: 80 GB/ 150 GB,
Windows 10/SSD: 150GB.
E5061B.
(Hard Disk Drive)
160 GB – [Revision Prefix: ELxxx, KY203 - KY221]
320 GB – [Revision Prefix: KY222]
(Solid State Drive)
80 GB – [Revision Prefix: KWxxx, YD472 - YD486]
150 GB – [Revision Prefix: YD488, YF]
E5063A
(Solid State Drive)
80 GB – [Revision Prefix: KA, KD, KE]
150 GB – [Revision Prefix: KE, FK]
N/A
N/A
The storage drive needs to be removed and replaced with a new or unused
hard disk drive part as per the service manual.
N/A
N/A
Memory for DSP (RAM) for A51 DSP Module
1.8M bit
Power rebooting. This is a volatile memory.
Power rebooting. This is a volatile memory.
This memory cannot be removed without damaging the instrument.
N/A
N/A
Page 8 of 16
Product Name: Network Analyzer
Model Number(s): E5061B/E5063A
