Freescale Semiconductor
User's Guide
FRDM-KL03Z User's Guide
1
Overview
The Freescale Freedom development platform is an
evaluation and development tool ideal for rapid
prototyping of microcontroller-based applications. The
hardware design is form-factor compatible with popular
third-party hardware designed to work with Arduino™
and Arduino-compatible boards.
The Freescale KL03Z freedom board (FRDM-KL03Z) is
a simple, yet sophisticated design featuring a Kinetis L
Series microcontroller KL03Z, a 3.3 V microcontroller
built on the ARM® Cortex™-M0+ core.
The Kinetis L series is the most scalable portfolio of
low-power, high-robustness, mixed signal 32-bit ARM
Cortex-M0+ MCUs running up to 48 MHz in the
industry. It supports power supply voltage range from
1.71 V to 3.6 V, ambient operating temperature ranges
from -40C to 105C and includes up to 64 KB flash.
The FRDM-KL03Z includes the Freescale open standard
embedded serial and debug adapter known as OpenSDA.
© 2014 Freescale Semiconductor, Inc. All rights reserved.
Document Number: FRDMKL03ZUG
Contents
1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2
Reference documents . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
4
FRDM-KL03Z hardware overview . . . . . . . . . . . . . . . . . . 2
5
FRDM-KL03Z hardware description . . . . . . . . . . . . . . . . 4
5.1
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5.2
Serial and Debug Adapter (OpenSDA) . . . . . . . . . . 6
5.3
Clock source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5.4
Serial port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.5
Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.6
Debug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.7
Capacitive touch slider . . . . . . . . . . . . . . . . . . . . . . 8
5.8
3-axis accelerometer . . . . . . . . . . . . . . . . . . . . . . . . 9
5.9
RGB LED. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.10 Input/output headers . . . . . . . . . . . . . . . . . . . . . . . 10
5.11 Arduino compatibility . . . . . . . . . . . . . . . . . . . . . . . 11
Rev. 0, 7/2014
Advertisement
Table of Contents
Related Manuals for Freescale Semiconductor FRDM-KL03Z
Summary of Contents for Freescale Semiconductor FRDM-KL03Z
-
Page 1: Table Of Contents
Getting started ....... . . 2 evaluation and development tool ideal for rapid FRDM-KL03Z hardware overview ....2 prototyping of microcontroller-based applications. The FRDM-KL03Z hardware description . -
Page 2: Reference Documents
A guide to the Arduino Uno revision Getting started Refer to the FRDM-KL03Z Quick Start Package for step-by-step instructions for getting started with the freedom board. See the “Jump Start Your Design” section on http://www.freescale.com/FRDM-KL03Z for the Quick Start Package and software lab guides. - Page 3 FRDM-KL03Z hardware overview Figure 1. FRDM-KL03Z block diagram The FRDM-KL03Z features two microcontrollers (MCUs): the target MCU and a serial and debug adapter (OpenSDA) MCU. The target MCU is a Kinetis L Series KL03 family device, the KL03Z32VFK4. The OpenSDA MCU is a Kinetis K Series K20 family device, the K20DX128VFM5.
-
Page 4: Frdm-Kl03Z Hardware Description
Power supply The FRDM-KL03Z offers a design with multiple power supply options. It can be powered from the USB connector, the VIN pin on the I/O header, an off-board 1.71–3.6 V supply from the 3.3 V pin on the I/O header or 3.3 V from motor control header. - Page 5 Regulated 3.3 V supply. Sources power to the P3V3 supply rail through a back drive protection Schottky diode. P3V3 Main supply rail for the FRDM-KL03Z. Can be sourced from P3V3_VREG. P3V3_MCU KL03Z MCU power supply. Header J10 provides a convenient means for KL03Z energy consumption measurements.
-
Page 6: Serial And Debug Adapter (Opensda)
LED (D1) and a RESET push button (SW1). The push button asserts the Reset signal to the KL03Z target MCU. It can also be used to place the OpenSDA circuit into Bootloader mode by holding FRDM-KL03Z User’s Guide, Rev. 0 Freescale Semiconductor... -
Page 7: Clock Source
The Kinetis KL03 microcontrollers feature an on-chip oscillator compatible with low ranges of input crystal or resonator frequencies: 32 KHz to 40 KHz (low frequency mode). The KL03Z on the FRDM-KL03Z is clocked from a 32,768 Hz crystal. FRDM-KL03Z User’s Guide, Rev. 0... -
Page 8: Serial Port
The sole debug interface on all Kinetis L Series devices is a Serial Wire Debug (SWD) port. The primary controller of this interface on the FRDM-KL03Z is the onboard OpenSDA circuit. However, a 25-pin (0.05”) Cortex Debug connector, J7, provides access to the SWD signals for the KL03Z MCU. -
Page 9: 3-Axis Accelerometer
GPIO signals as shown in Table 4. By default, the I C address is 0x1D (SA0 pulled high). Table 4. Accelerometer signal connections MMA8451Q KL03Z PTB3 PTB4 INT1 — INT2 PTA12 Figure 6. Accelerometer connection FRDM-KL03Z User’s Guide, Rev. 0 Freescale Semiconductor Freescale Semiconductor... -
Page 10: Rgb Led
The MKL03Z32VFK4 microcontroller is packaged in a 24-pin QFN. Some pins are utilized in on-board circuitry, but many are directly connected to one of four I/O headers (J1, J2, J3, and J4). FRDM-KL03Z User’s Guide, Rev. 0 Freescale Semiconductor Freescale Semiconductor... -
Page 11: Arduino Compatibility
Figure 8. I/O headers 5.11 Arduino compatibility The I/O headers on the FRDM-KL03Z are arranged to allow compatibility with peripheral boards (known as shields) that connect to Arduino and Arduino-compatible microcontroller boards. The pins on the FRDM-KL03Z User’s Guide, Rev. 0... - Page 12 Freescale, the Freescale logo, and Kinetis are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. All other product or service names are the property of their respective owners.
