HANSFORD GRANDE
Assembly & Installation Instructions

Parts Supplied

Ref Description Illustration Qty
A Mantel
Suite with
Electric Fire
Before You Start
DO NOT dispose of the packaging until you have checked and made
sure you have all the parts and fittings listed above. If not, contact
BE MODERN HELPLINE on 0191 430 0901
who will be able to assist you with this and any other problems you may
have encountered.
When you are ready to start, make sure that you have the right tools to
hand, plenty of space and a clean dry working area.
NB. Protect the surface you are working on to prevent any possible
damage to the fire surround or floor.

Fire Instructions

For fire instructions please refer to separate instructions supplied.

Care

To maintain the appearance of your new suite we recommend that it is dusted
using a lint free cloth. NEVER use any form of abrasive or DAMP cloth.

Tools (not supplied) For Fixing To Wall

Drill
Screw Driver
Tape Measure

Fittings Supplied

Ref Description Illustration Qty
B
1
C
D
Pencil
Ruler
Mantel
Brackets
Wall
Brackets
16mm
Screws
2
2
4
:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HANSFORD GRANDE and is the answer not in the manual?

Questions and answers

Summary of Contents for bemodern HANSFORD GRANDE

  • Page 1 HANSFORD GRANDE Assembly & Installation Instructions Parts Supplied Fittings Supplied Ref Description Illustration Qty Ref Description Illustration Qty Mantel A Mantel Brackets Suite with Electric Fire Wall Brackets 16mm Screws Before You Start • DO NOT dispose of the packaging until you have checked and made sure you have all the parts and fittings listed above.
  • Page 2 Installing The Mantel Trial fit the mantel in the required position. Remove any obstructions, ie. cut to shape or Fig.1 remove skirting to allow the mantel to butt up to the wall. Note: Mantel is a two adult person lift. 100mm Screw the 2 mantel brackets (B) to the inside of each leg using the 4 screws...
