bemodern BM-06 2 SLIDE Series User Instructions

Widescreen he gas fire
Hide thumbs
Table of Contents

Advertisement

Quick Links

WIDESCREEN HE GAS FIRE
USER INSTRUCTIONS
INSTALLATION INSTRUCTIONS
SERVICE INSTRUCTIONS
It is a regulation that these instructions be handed to the customer after installation is complete. It is
also the responsibility of the installation engineer to ensure that the customer is able to fully operate
the appliance and is aware of any cleaning or maintenance requirements.
Model number: BM-06XXX2 SLIDE for use on Natural Gas (G20) at a supply pressure of 20 mbar in GB / I.E.
(XXX denotes Fret Type, Fuel Bed Type & Trim Type)
NOTE:
The installation of this appliance requires a
back panel with a specific cut out — See page 5 for details
P-XX1551 ISSUE5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BM-06 2 SLIDE Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for bemodern BM-06 2 SLIDE Series

Summary of Contents for bemodern BM-06 2 SLIDE Series

  • Page 1 WIDESCREEN HE GAS FIRE USER INSTRUCTIONS INSTALLATION INSTRUCTIONS SERVICE INSTRUCTIONS It is a regulation that these instructions be handed to the customer after installation is complete. It is also the responsibility of the installation engineer to ensure that the customer is able to fully operate the appliance and is aware of any cleaning or maintenance requirements.

  • Page 2: Table Of Contents

    CONTENTS Regulatory Information and Installation Requirements …………………………... 3 Installation Requirements (continued) ………………………………………………….. 4 Siting the Appliance ……………………………………………………………………………… 5 Installation of ‘fixing plate’ assembly …..………………………………………………. 6 Installing the Back Panel …………………………………………………………………………. 7 Fixing the Appliance ……………………………………………………………………………… Connecting the Appliance to the Gas Supply ……………………………………….. Front glass removal and replacement …………………………………………………….

  • Page 3: Regulatory Information And Installation Requirements

    REGULATORY INFORMATION AND INSTALLATION REQUIREMENTS THE FOLLOWING MUST BE NOTED PRIOR TO THE INSTALLATION OF THIS APPLIANCE. This gas appliance MUST be installed by a GAS SAFE registered installer by law. It must be installed in accordance to these installation instructions and the GAS SAFETY (Installation & Use) REGULATIONS 1998 as amended.

  • Page 4: Installation Requirements (Continued)

    No purpose made ventilation is normally required for this appliance when installed in G.B. If the appliance is being installed in I.E then refer to I.S 813:1996 (Domestic Gas Installation—National Standards Authority of Ireland). Ventilation areas (if applicable) should be checked periodically to ensure there is no obstruction, even though none is normally required for this appliance.

  • Page 5: Siting The Appliance

    SITING THE APPLIANCE Fireplace Opening IMPORTANT NOTE: This appliance DOES NOT seal onto a marble or stone back panel. The fire is installed directly onto the FIXING PLATE assembly. This is detailed on pages 6 & 7. This FIXING PLATE is also used to support the marble or stone back panel. This back panel should have the following cut- out : WIDTH 560mm—580mm HEIGHT: 585mm—605mm...

  • Page 6: Installation Of 'Fixing Plate' Assembly

    Checking the Flue Use a smoke pellet prior to the appliance installation to ensure the viability of the flue and check that the smoke can be seen being emitted from the terminal / chimney pot outside. There must be no leakage of smoke through the structure of the chimney/flue during or after the smoke pellet test and it is important to check inside upstairs rooms adjacent to the chimney/flue.

  • Page 7: Installing The Back Panel

    Installing the Back Panel Ideally the back panel should be constructed from a 3 piece panel and reassembled using suitable materials. This type of back panel will ensure that no corner cracking occurs over time. A ’loose’ 3 piece panel can be installed but care should be taken to ensure that the joint line is square.
  • Page 8 Now unroll and fit the rock wool as shown below. This should sit around the perimeter of the FIXING PLATE. Under NO circumstances should this fireplace be commissioned without the installation of the Rockwool provided. The mantel can now be fitted, and the back panel adjusted into the correct position.

  • Page 9: Fixing The Appliance

    Prepare the Appliance for Installation Remove the glass front panel and the ceramic components from the unit (see glass removal instructions on page 10). Remove the burner tray from the appliance. (For instructions see page 14). If the concealed installation method is chosen, there are three optional entry points at the rear/side of the appliance. The relevant ‘knock-out’...

  • Page 10: Front Glass Removal And Replacement

    Removal of the front glass panel. The top glass clamp is held in place with 3 screws. This panel is concealed behind the top cover strip which is held in place by two magnets. The two magnets are fitted to the top glass clamp as shown in this diagram.

  • Page 11: Checking Operation Of Appliance

    Install the ceramics into the appliance according to these instructions—see pages 17 through to 23. Refit the glass panel and the decorative strip to cover the screws and retaining clamp—See page 10 Test the operating pressure of the appliance by attaching a pressure gauge to the test point of the appliance. This connection should take place when the appliance is OFF.

  • Page 12: Completing The Installation

    Completing the Installation of the Appliance Remove the protective covering (if applicable) from the face of the decorative trim. To fit the trim to the appliance the four adjustable mounting features at the rear of the trim need to be set. To allow for a tolerance with the installation the trim can be adjusted to sit fore and aft as is required to give a neat fit of the trim.

  • Page 13: Appliance Technical Information

    Appliance Technical Information Gas Type : Natural Gas Category : I2H Inlet Pressure: (Cold) 20mbar Heat Input Gross : 5.5kW Injector : 69 Destination Countries : GB/ IE HEALTH AND SAFETY NOTICE This appliance uses fuel effect pieces manufactured from Refractory Ceramic Fibres (RCF). Care must be taken to avoid excessive exposure to these materials as they may cause irritation to the eyes, skin, nose and throat.

  • Page 14: Cleaning Instructions

    Cleaning the Appliance (continued) Trim, Fret and Painted Metal Parts There are a variety of trim and fret options which may have been supplied with your appliance and these are normally a plated material on a steel substrate. It is important that no abrasive cleaners or chemical agents are used in the cleaning of these components.

  • Page 15: Service Instructions

    Removal / Replacement of Gas Carrying Components (continued) Slide Control Valve Remove the locknut from the front of the valve. Undo the three (3) nuts around the periphery of the valve body—Gas Inlet / Burner / Pilot. Remove the thermocouple nut from the back of the valve. The valve can be removed and serviced / replaced as necessary.

  • Page 16: User Instructions

    OPERATING INSTRUCTIONS This appliance is available with two operating methods, namely manual control and slide control. The following instructions detail both methods of operation however the basic operation of the appliance involves the ignition of a pilot burner (See page 11 for spillage monitoring details—ODS), then the control of the main burner with LOW and HIGH settings.

  • Page 17: Log Layout Instructions

    FUEL BED LAYOUT (COAL) The following instructions detail how the ceramic fuel bed and loose components are to be installed onto the appliance. Great care should be taken when handling these ceramic parts as they are fragile and can easily be broken. Do not force any component into position, if it does not fit easily then you are not fitting the part correctly.
  • Page 18 Step 3 Fit the Right Hand front ceramic rail in front of the burner as shown in the picture below. Step 4 Fit Log A onto the fuel bed as shown in the picture below.
  • Page 19 Step 5 Fit Log B onto the fuel bed as shown in the picture below. Step 6 Fit Log C onto the fuel bed as shown in the picture below.
  • Page 20 Step 7 Fit Log D onto the fuel bed as shown in the picture below. Step 8 Fit Log E onto the fuel bed as shown in the picture below.
  • Page 21 Step 9 Fit Log F onto the fuel bed as shown in the picture below. Step 10 Fit Log G onto the fuel bed as shown in the picture below.
  • Page 22 Step 11 Fit Log H onto the fuel bed as shown in the picture below. (Note this log sits partially hidden behind log ‘F’) Step 12 Fit Log I onto the fuel bed as shown in the picture below.

  • Page 23: Fit Trim To The Appliance

    Step 13 Fit Log J onto the fuel bed as shown in the picture below. Now refit the glass panel, retainer and trim cover—see page 10 for details Fit Trim to Appliance The trim has four adjustable fittings on the rear face. By winding the screws in and out, the position of the trim can be adjusted.

  • Page 24: Spare Parts List

    Tel: 0191 489 8006 Fax: 0191 580 0085 Email: sales@bemodern.com Due to our policy of continual product improvement, some diagrams and small details may not be accurate however if there is any concern or matter of understanding that you feel needs to be clarified please contact us directly. Our contact details are shown above.
