Steelcase RoomWizard Retrofit Installation Instructions page 11

Privacy Wall (with 1" flange - continued)
5. Route the PoE cable through the glass mounting bracket.
6. Peel the adhesive backing film from the adhesive mounting
strips on the back of the glass mounting bracket. Ensuring
the glass mounting bracket is level and against the PoE cable
cover then press the glass mounting bracket onto glass.
Hold even pressure for at least 15 seconds.
7. Plug the PoE cable into the back of the RoomWizard.
8. Install the RoomWizard module into the glass mount
bracket.
9. Peel or cut the tabs on the protective cover, then slide to
remove the protective cover.
8
9
Peel or cut the tabs on the protective cover
RoomWizard
Retrofit Installation Instructions
5
7
Mounting Kits
©
6
REMOVE ADHESIVE BACKING
FILM FROM ADHESIVE STRIPS
Page 11 of 22
