Via Glass Wall Systems - Steelcase RoomWizard Retrofit Installation Instructions

VIA Glass – Retrofit
1. Remove the existing RW20 mount bracket
from the existing VIA Mount. See Page 4 for
details.
2. Route the PoE cable through the mounting
wall mount bracket and VIA mount adapter.
Be sure step on VIA mount adapter is inserted
into existing VIA mount.
3. Insert the four (4) screws provided with the
mount kit and tighten with a #2 Phillips
screwdriver. Make sure the mount bracket is
level before final tightening.
STEP
1
2
RoomWizard Mounting Kits
©
Retrofit Installation Instructions
RW20 Mount Bracket
3
Existing VIA Mount
Bracket
Page 14 of 22
