Unitronics V200-18-E2B Quick Start Manual page 9

1 0 / 0 6
Transistor Outputs
Number of outputs
Output type
Galvanic isolation
Output current
Maximum frequency
High speed output maximum
frequency (resistive load).
ON voltage drop
Short circuit protection
Power supply
operating voltage
nominal operating voltage
npn (sink) power supply
operating voltage
Notes:
4. Outputs #12 and Output #13 may be used as high-speed outputs
Analog Inputs
Number of inputs
Input range
Conversion method
Resolution (except at 4-20mA)
Resolution at 4-20mA
Conversion time
Input impedance
Galvanic isolation
Absolute maximum rating
Full-scale error
Linearity error
Unitronics
V 2 0 0 - 1 8 - E 2 B
4. Each can be individually wired as pnp (source) or npn (sink).
pnp: P-MOSFET (open drain)
npn: open collector
Yes
pnp: 0.5A maximum (per output)
Total current: 2A maximum (per group)
npn: 50mA maximum (per output)
Total current: 150mA maximum (per group)
20Hz (resistive load)
0.5Hz (inductive load)
pnp: 2kHz
npn: 50kHz
pnp: 0.5VDC maximum
npn: 0.85VDC maximum
See Note 4
Yes (pnp only)
20.4 to 28.8VDC
24VDC
3.5V to 28.8VDC,
unrelated to the voltage of either the I/O module or the controller
2 (single-ended)
0-10V, 0-20mA , 4-20mA. See Note 5.
Successive approximation
10-bit (1024 units)
204 to 1023 (820 units)
Synchronized to scan time
>100KΩ—voltage
500Ω—current
None
±15V—voltage
±30mA—current
±2 LSB (0.2%)
±2 LSB (0.2%)
S n a p - i n I / O M o d u l e
9
