Unitronics V200-18-E2B Quick Start Manual page 8

V 2 0 0 - 1 8 - E 2 B
S n a p - i n I / O M o d u l e
V200-18-E2B Technical Specifications
Digital Inputs
Number of inputs
Input type
Galvanic isolation
Nominal input voltage
Input voltage
pnp (source)
npn (sink)
Input current
Response time
High speed inputs
Resolution
Frequency
Minimum pulse width
Notes:
1. Inputs #0 and #2 can each function as either high-speed counter or as part of a shaft encoder. In
each case, high-speed input specifications apply. When used as a normal digital input, normal
input specifications apply.
2. Inputs #1 and #3 can each function as either counter reset, or as a normal digital input; in either
case, its specifications are those of a normal digital input. These inputs may also be used as part
of a shaft encoder. In this case, high-speed input specifications apply.
Relay Outputs
Number of outputs
Output type
Isolation
Type of relay
Output current
Rated voltage
Minimum load
Life expectancy
Reponse time
Contact protection
Outputs' power supply
Nominal operating voltage
Operating voltage
Max. current consumption
Notes:
3. Outputs #1, #2, #3, and #4 share a common signal. All other outputs have individual contacts.
8
16 (in two groups)
pnp (source) or npn (sink), set by wiring.
Yes
24VDC
0-5VDC for Logic '0'
17-28.8VDC for Logic '1'
17-28.8VDC for Logic '0'
0-5VDC for Logic '1'
6mA@24VDC for inputs #4 to #15
8.8mA@24VDC for inputs #0 to #3
10mSec typical
Specifications below apply. See Notes 1 and 2.
32-bit
10kHz maximum
40μs
10. See Note 3.
SPST-NO relay (Form A)
By relay
Panasonic JQ1AP-24V, or compatible
5A maximum (resistive load ).
8A maximum for common signal. See Note 3.
250VAC / 30VDC
1mA@5VDC
50k operations at maximum load
10mS (typical)
External precautions required . See Increasing Contact Life Span, page 5.
24VDC
20.4 to 28.8VDC
90mA@24VDC
