5. Align the guide on each side of the inner chassis (below-left) so that they rest under the bottom grooves
on the outer case (below-center), and slide the inner chassis back into the case (below-right).
Mercury Elite Pro
6. Reseat the back plate so that it sits flush with the edge of the
enclosure, as well as the USB port and power switch.
7. Re-affix the screws you removed in Step 1. The Mercury Elite Pro
is now ready to use.
5
Device Setup
