Summary of Contents for Winmate R15IK3S-67C3(HB)
- Page 1 15” G-WIN Rugged Panel PC Full IP67 Model No. R15IK3S-67C3(HB) R15IH3S-67A3(HB) R15IB3S-67A3(HB) R15ID3S-67A3(HB Quick Start Guide Document Version 1.1 Document Part No. 9152111I102C Please read these instructions carefully before using this product, and save this manual for future use.
-
Page 2: Table Of Contents
4.2 Wiring Requirements 4.3 Connecting to Other Devices 4.4 Connector Description 4.4.1 Power Input Connector 4.4.2 Ethernet Connector 4.4.3 Serial Interface Connector 4.4.4 USB 2.0 Connector Appendix Appendix A: Specifications Appendix B: Cleaning the Monitor Appendix C: Winmate Software Development Kit... - Page 3 Chapter 1: Introduction FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received including interference that may cause undesired operation.
- Page 4 Warranty Winmate Inc. warranty guarantees that each of its products will be free from material and workmanship defects for a period of one year from the invoice date. If the customer discovers a...
-
Page 5: Chapter 1: Introduction
Chapter 1: Introduction Chapter 1: Introduction Congratulations on purchasing Winmate® 15-inch G-WIN Rugged Panel PC with full IP67 waterproof rating. Panel PC features 15” panel with sunlight readable screen, fanless cooling system, low power consumption, WLAN integration, shock and vibration resistant. The robust design fits the demands for every harsh environment applications such as logistics, transportation/ fleet management, heavy vehicles, utility and also outdoor usage. -
Page 6: Description Of Parts
15" G-WIN Rugged Panel PC Quick Start Guide 1.3 Description of Parts Unit: mm Dimensions: 398 x 308 x 58 № Description ① LAN (M12 Type) ② USB (M12 Type) ③ RS232 (M12 Type) ④ 9-36V DC (M12 Type) ⑤ OSD Control Panel... -
Page 7: Physical Buttons And Led Indicators
Chapter 1: Introduction 1.4 Physical Buttons and LED Indicators Physical buttons and LED indicators (OSD Control Panel) are located on the rear side of the panel PC. - Page 8 15" G-WIN Rugged Panel PC Quick Start Guide Physical Buttons Icon Button Function Power Turn ON or turn OFF the panel PC. Clear any pending errors or events and brings a system Reset to normal condition or an initial state. Lock / Unlock Tap this button to lock / unlock the function of OSD panel.
-
Page 9: Chapter 2: Getting Started
Chapter 2: Getting Started Chapter 2: Getting Started 2.1 Turning On and Off Your Device To turn on you’re your device: 1. Remove the protective cap of the power connector. 2. Connect power cable to the connector of your device. Make sure the cable fits to the connector, then tighten the O-ring (by turning clockwise) to secure the connection. - Page 10 15" G-WIN Rugged Panel PC Quick Start Guide To shut down your device: 1. Select the Start button ( ) and then select Power > Shut down. 2. Disconnect the power cord from the Panel PC to completely turn off the device. To forcibly shut down your device, press and hold for three to five seconds the power button located on the front OSD control panel.
-
Page 11: How To Enable Watchdog
2.2 How to Enable Watchdog To enable Watchdog, download Winmate Watchdog utility. Find more information about Watchdog in “Watchdog Guide” that you can download from Winmate Download Center. To enable watchdog in Watchdog AP follow the instructions below: 1. On the right bottom side of the desktop screen, click triangle button to show hidden icons. -
Page 12: Chapter 3: Mounting
VESA Plate 15” 100x100 mm Mounting Instruction Use Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device. *The picture is for demonstration purposes only. VESA Mounting accessories are not supplied by Winmate. -
Page 13: Dash/ Yoke Mount
Chapter 3: Mounting 3.2 Dash/ Yoke Mount You can purchase mounting bracket from Winmate as an optional accessory. Part Number: 99KK15A00001 Mounting instruction: 1. Place the Panel PC on the bracket stand, aiming screw hole for each other. 2. Secure three M5x10 screws to fix the device upon the bracket stand. - Page 14 15" G-WIN Rugged Panel PC Quick Start Guide 4. Loosen the hand-screw adjustment tool, then you can adjust product angle on the stand. Then screw the product tightly again to secure the stand position. Desk Stand Dimensions...
-
Page 15: Chapter 4: Installation
Chapter 4: Installation Chapter 4: Installation 4.1 Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. -
Page 16: Connecting To Other Devices
15" G-WIN Rugged Panel PC Quick Start Guide 4.3 Connecting to Other Devices This Panel PC comes with various interfaces located on the bottom panel. All of these connectors have been shipped with protective caps. To ensure the waterproof function can work properly, make sure that the protective caps and have been securely tightened whenever the connectors are not used. -
Page 17: Connector Description
Chapter 4: Installation 4.4 Connector Description The panel PC features M12 type waterproof connectors covered with protective caps. 4.4.1 Power Input Connector Panel PC has M12 type 3 pin male power input connector which accepts 9-36 V DC power input. Use waterproof power cable to connect the Panel PC to the source of power. -
Page 18: Ethernet Connector
15" G-WIN Rugged Panel PC Quick Start Guide 4.4.2 Ethernet Connector Panel PC has M12 type Ethernet connector. Use waterproof LAN cable to connect the panel PC to the Ethernet. LAN Cable... -
Page 19: Serial Interface Connector
Chapter 4: Installation 4.4.3 Serial Interface Connector Panel PC has M12 type 10 pin male RS-232 connector. Use waterproof serial cable to connect the panel PC to external devices. COM Cable... -
Page 20: Usb 2.0 Connector
15" G-WIN Rugged Panel PC Quick Start Guide 4.4.4 USB 2.0 Connector Panel PC has M12 12 pin male USB connector. Use waterproof USB 2.0 cable to connect the panel PC to external devices. USB Cable... -
Page 21: Appendix
Appendix Appendix Appendix A: Specifications Hardware Specifications Model Name R15IK3S-67A3(HB) R15IH3S-67A3(HB) R15IB3S-67A3(HB) R15ID3S-67A3(HB) Display 15” 15” 15” 15” Size/ Type Resolution 1024 x 768 1024 x 768 1024 x 768 1024 x 768 Std: 400 nits Std:: 400 nits Std:: 400 nits Std:: 400 nits Brightness Opt.: 1000 nits... - Page 22 15" G-WIN Rugged Panel PC Quick Start Guide Model Name R15IK3S-67A3(HB) R15IH3S-67A3(HB) R15IB3S-67A3(HB) R15ID3S-67A3(HB) Power Specifications 9~36V DC in with 9~36V DC in with 9~36V DC in with 9~36V DC in with isolation. Optional isolation. Optional 6- isolation. Optional 6-60V isolation.
-
Page 23: Appendix B: Cleaning The Monitor
Don not use water or oil directly on the display screen. If droplets are allowed to drop on the screen, permanent staining or discoloration may occur. Appendix C: Winmate Software Development Kit Winmate® provides Software Development Kit (SDK). The table below lists SDK provided by Winmate for 15” G-WIN Rugged Full IP67 panel PC: Item... - Page 24 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © Winmate Inc. All rights reserved.
