- Page 1 Instructions for Use StatSpin Express 3 Centrifuge Model Number M502-22 This manual is intended for SSX3 - Express 3 for 100 to 240 VAC, 50/60 Hz 55-005187-001EC September 2018 Beckman Coulter, Inc. 250 S. Kraemer Blvd. Brea, CA 92821 U.S.A.
- Page 2 Trademarks Beckman Coulter, the stylized logo, and the Beckman Coulter product and service marks mentioned herein are trademarks or registered trademarks of Beckman Coulter, Inc. in the United States and other countries. All other trademarks are the property of their respective owners.
- Page 3 Proposition 65 statement 55-005187-001 EB, 03/2018 • Converted the StatSpin Express 3 Operations Manual to a Beckman Coulter Instructions for Use (IFU) manual, and made general clarifications to the IFU • Added: Revision History, Safety Notice, Symbols and Definitions table, Alerts for...
- Page 4 Revision History 55-005187-001EC...
- Page 5 Safety Notice Read all product manuals and consult with Beckman Coulter-trained personnel before you operate the system. Do not perform any procedure before you carefully read all instructions. Always follow the product labels and the manufacturer’s recommendations. If you have any questions: •...
- Page 6 Handle and dispose of sharp fragments according to the World Health Organization's Laboratory Biosafety Manual and relevant local and national regulations. Warning If the equipment is used in a manner not specified by Beckman Coulter, the protection provided by the equipment may be impaired. Warning Inspect the instrument for cracks or any physical damage to housing, cover, and rotor upon the receipt of the unit.
- Page 7 In addition, other equipment can radiate radio frequency energy to which the system is sensitive. If you suspect interference between the system and other equipment, Beckman Coulter recommends the following actions to correct the interference: •...
- Page 8 Safety Notice Express 3 Warning and Cautions Caution Do not spray cleaning solutions directly onto the centrifuge bowl or housing. Overspray can reach the motor bearings or internal circuitry, causing harm to the electronics. Before using any cleaning or decontamination methods other than those recommended by the manufacturer, users should check with the manufacturer that the proposed method will not damage the equipment.
- Page 9 Safety Notice Express 3 Warning and Cautions Caution The cover interlock bypass is for emergency use only. Disconnect the power cord from the wall outlet and ensure the rotor has come to a complete stop before using the interlock bypass. If the equipment is not used correctly, safety can be impaired. Caution The instructions prohibit use of the specified materials within the centrifuge •...
- Page 10 Safety Notice Symbols and Definitions Symbols and Definitions Table 1 Express 3 Symbols Glossary Symbol Description Warning; Biological hazard To warn of a biological hazard. IEC 60878. Graphical Symbols for electrical equipment in medical practices. #7010-W009 Supplemental Product-Specific Manufacturer Information This label indicates a caution to operate only with all covers in position to decrease risk of personal injury or biohazard.
- Page 11 Safety Notice Symbols and Definitions Table 1 Express 3 Symbols Glossary (Continued) Symbol Description cNRTLus Certification Mark This symbol indicates recognition by a Nationally Recognized Testing Laboratory (NRTL) that the system has met the relevant product safety standards for the United States and Canada. OSHA, CEC RCM Symbol This symbol indicates compliance with the Australian Communications...
- Page 12 Safety Notice Symbols and Definitions Table 1 Express 3 Symbols Glossary (Continued) Symbol Description RoHS Caution Symbol This symbol indicates that this electronic information product contains certain toxic or hazardous elements, and can be used safely during its environmental protection use period. The number in the middle of the logo indicates the environmental protection use period (in years) for the product.
- Page 13 Safety Notice Symbols and Definitions Table 1 Express 3 Symbols Glossary (Continued) Symbol Description Fuse To identify fuse boxes or their location. IEC 60417: Graphical symbols for use on equipment - Overview and application, #5016 Supplemental Product-Specific Manufacturer Information This symbol is used to identify a fuse location and rating. Protective earth;...
- Page 14 Safety Notice Symbols and Definitions Table 1 Express 3 Symbols Glossary (Continued) Symbol Description California Proposition 65 This product can expose you to chemicals known to the State of California to cause Cancer and Reproductive Harm. For more information go to https://www.P65Warnings.ca.gov.
-
Page 15: Table Of Contents
Contents Revision History, iii Safety Notice, v CHAPTER 1: Installation, 1-1 Inspecting the Packaging, 1-1 Confirming the Contents, 1-1 Installing the System, 1-1 Connecting the Power, 1-1 CHAPTER 2: System Overview, 2-1 Intended Use, 2-1 Operator Controls, 2-1 Error Indicators, 2-2 Accessories, 2-3 CHAPTER 3: Operating... - Page 16 Contents 55-005187-001EC...
-
Page 17: Installation
CHAPTER 1 Installation Inspecting the Packaging The StatSpin Express 3 and its accessories are delivered in one carton. If the centrifuge or accessories have suffered any damage in transport, inform your carrier immediately. Note Save shipping carton and components to simplify return if service is required. - Page 18 Installation Connecting the Power Turn on the power switch (located on the rear panel, above the line cord connector). When the instrument is ready for use, it will give a two beep signal and illuminate the two minute cycle light on the front keypad. Press the stop button to release the latch and open the cover.
-
Page 19: System Overview
CHAPTER 2 System Overview Intended Use The StatSpin Express 3 is a high-speed bench top centrifuge used to rapidly separate whole blood in the original sample collection tubes. The eight-place 30° angle rotor included with the centrifuge produces rapid separation while minimizing potential for re-suspension of cells. -
Page 20: Error Indicators
System Overview Error Indicators Error Indicators Express 3 error conditions are signaled by a flashing red Error or Service indicator on the front panel. The cause of the error condition can be identified by the combination of green cycle time indicators that are also flashing. -
Page 21: Accessories
3 min and 5 min lights and red indicator flashing Accessories The following accessories list identifies some common items that are used on the Express 3. If the part you need is not on the list, contact your Beckman Coulter Support Center for assistance. 55-005187-001EC... - Page 22 System Overview Accessories Table 2.3 Accessories Product No. Description SV02 Inserts for 3 mL tubes (10.25 x 64 mm) 4/pk. SV05 Inserts for 2 mL tubes (BD Microtainers) 4/pk. SV06 Inserts for 7 mL tubes (16 x 75 mm) 8/pk. SV07 Inserts for 10 mL tubes (16 x 100 mm) 8/pk.
-
Page 23: Operating Instructions
CHAPTER 3 Operating Instructions Opening and Closing the Cover The electrically operated cover interlock mechanism prevents operation until the cover is completely closed and locked, and prevents the cover from being opened while the centrifuge is in operation. When the cover is completely closed and locked, an operating cycle can be initiated. -
Page 24: Reinstalling The Rotor
Loading Be sure the correct tube inserts are installed. The StatSpin Express 3 centrifuge is provided with eight tube inserts for 13 x 75-mm tubes (Product No. SV08) and eight tube inserts for 16 x 100-mm tubes (Product No. SV07). Other sizes are available (For more information, refer to Accessories.) -
Page 25: Cycle Selection
Operating Instructions Spinning the Sample Close and latch the centrifuge cover. Select the spin time by pressing the appropriate cycle time button. Press the Start button. Cycle Selection Select spin time settings to achieve optimum results for specific applications. Table 3.1 Cycle Selection Setting Description... - Page 26 Operating Instructions Spinning the Sample 55-005187-001EC...
-
Page 27: Maintenance
Maintenance Overview Beckman Coulter recommends that instrument operators perform periodic inspections and preventative maintenance on all devices. Contact Beckman Coulter at any time if the instrument is not functioning correctly. Caution Disconnect the power cord from the electrical outlet before performing maintenance or inspection. -
Page 28: Disinfecting The Rotor
Do not defeat any safety interlocks while performing the test. If the StatSpin Express 3 fails to achieve an operating speed of 7200 rpm ±5% in the 2 min and 3 min settings or 5600 rpm ±5% in the 5 min setting, contact Beckman Coulter Customer Support. 55-005187-001EC... -
Page 29: Replacing The Fuse
Is the instrument completely plugged into the Plug power cord into the electrical electrical outlet? outlet. Is the electrical outlet working correctly? Try another electrical outlet. Check the fuse. Replace fuse. Is the fuse open? Contact Beckman Coulter Customer Support. 55-005187-001EC... -
Page 30: Service
Beckman Coulter cannot perform decontamination. Limited Warranty and Disclaimer: Subject to the below exceptions and conditions, Beckman Coulter warrants to the original purchaser that the Equipment will shall be free from substantial defects in material, under normal use and service, for the period expiring twenty-four (24) months and (ii) Services will be performed in a workmanlike manner. - Page 31 Representations and warranties made by any representatives, salespersons or agents of Beckman Coulter, which are inconsistent or in conflict with or in addition to the terms of this Agreement, will not be binding upon Beckman Coulter unless reduced to writing and approved by an expressly authorized officer of Beckman Coulter.
- Page 32 Maintenance Service 55-005187-001EC...
-
Page 33: Appendix A: Specifications
APPENDIX A Specifications Specifications Product Number SSX3 Model Number M502-22 Spin Parameters 2 minutes: 120 seconds at 7,200 rpm, 4,440 xg 3 minutes: 180 seconds at 7,200 rpm, 4,440 xg 5 minutes: 300 seconds at 5,600 rpm, 2,685 xg Acceleration Time ≤25 seconds Deceleration Time ≤30 seconds... -
Page 34: Specifications
Specifications Specifications 55-005187-001EC... -
Page 35: Appendix B References
APPENDIX B References References 1. CLSI. Protection of Laboratory Workers from Occupationally Acquired Infections; Approved Guideline-Second Edition. CLSI document M29-A2 [ISBN 1-56238-453-8]. CLSI, 940 West Valley Rd, Suite 1400, Wayne, Pennsylvania 19087-1898 USA, 2001. 2. CDC. Recommendations for Prevention of HIV Transmission in Health Care Settings. MMWR (Suppl. - Page 36 References References 55-005187-001EC...
- Page 38 © 2018 Beckman Coulter, Inc. All Rights Reserved.
