Ultra Whole House Well Water Filter System Combo
PLEASE READ INSTRUCTIONS FULLY PRIOR TO ATTEMPTING INSTALLATION. Be sure to follow
all applicable plumbing codes. The system must be installed on a main water supply line

System Configuration

Water Source
From Your Well
(1) The Well Water
Filter uses an air
injecting oxidation
filter to remove iron,
sulfur, and
manganese from
your water
Level Tanks
Leaning Tank
Tank Boot
If the tank is not perfectly straight, carefully lift the tank straight up a few inches and tap it on the ground until
the tank stands vertically and fits snuggly into the tank boot.
1 2
(2) The sediment
filter eliminates
any particulate
Questions? Call (800)-589-5592
3
(3) The Carbon
Filter will
eliminate
contaminants
Filtered and Softened
Water Into Home
4
(4) The Softener
will neutralize
any remaining
particulate
