SpringWell ULTRA UWS1 Installation Instructions Manual page 14

Ultra Whole House Well Water Filter System Combo
Installing the Tanks – Part 1
51) Position the well water tank
next to incoming pre-plumb
with its connections facing back
Installing the Drain Line (Well Water
This step will require the materials listed below
50' Drain Line
55) Remove the blue lock tab
securing the drain valve in place.
52) Connect a water connector
to the PVC nipple coming out
from the shut off valve.
Filter)
Hose
Clamp
56) Pull the drain valve straight
out.
Questions? Call (800)-589-5592
Zip Ties
53) Connected the corrugated
pipe to the incoming side on
the back of the well water
filter. Ensure it is fully
tightened.
54) Locate the drain valve on the
left side of the well water filter
head. It is a compression
connection.
57) Slide a hose clamp over an
end of one of the provided drain
lines.
14
