System Contents
Well Water
Filter Tank
Recommended Supplies
1-inch (24-inch Long) Corrugated
Water Connectors (x2)
1-inch threaded connectors for pre-
plumb (slip/threaded elbows shown)
System Configuration
Water Source
From Outside Home
(1) Water from your
source will be softened by
the ion exchange softener
Well Water Filter System
Setup and Installation
Electronic
Head for Well
Water Filter
(Tank 1)
1-inch (3-inch long) PVC Nipple
1-Inch PVC Shut Off Valve
Questions? Call (800)-589-5592
MNPT Fittings
50' Drain Line
1
Bypass Valve
Power
Supply
1 Roll Plumbers Tape
Zip Ties
Softened
Water Into Home
(2) The salt from your
2
brine tank will regularly
regenerate the media in
your softening system
Hose
Clamp
2
