System Contents

Carbon Filter
Tank (CF+)

Recommended Supplies

1.5-inch Tee
Connector (Slip) (x2)
* The quantities are suggestions. Your system configuration may vary depending on installation area.

System Configuration

Water Source
From Outside Home
(1) Water from your
source will begin by
entering the Pre-Filter
CF+ System

Setup And Installation

Pre-Filter
1.5-inch Elbow
Connector (Slip) (x8*)
Primer and Cement
1
Questions? Call (800)-589-5592
Spanner
Wrench
Sediment
Filter
Gasket and Lube
1.5-inch Adapter (Slip
x Thread) (x4)
1.5-inch PVC Pipe (10' used in this
manual)
2
(2) The Carbon Filter
Filter (CF+) will be the
second tank and will
remove chemicals such
Hose Bib
Assembly (2)
Mounting
Bracket
1.5-Inch PVC Shut Off
Valves (x3)
Filtered and Softened
Water Into Home
as chlorine
1 Roll Plumbers
Tape
