Installation Instructions
WHOLE HOUSE WATER FILTER
MODELS: SWCF0948, SWCF1054, SWCF1354
SpringWell whole house water filters use the highest
quality of coconut catalytic carbon that target the
contaminants that we find in our water supplies today.
Our systems are manufactured in an up-flow design
giving the influent water optimal contact time so we can
reduce as many contaminants as possible. Our catalytic
carbons have an extremely fast reaction time which
means more contaminant removal, even in a high flow
installation.
CUSTOMER SERVICE IS AVAILABLE MON-FRI 9AM-6PM EST
800-589-5592
WWW.SPRINGWELLWATER.COM
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SpringWell SWCF0948
Summary of Contents for SpringWell SWCF0948
- Page 1 Installation Instructions WHOLE HOUSE WATER FILTER MODELS: SWCF0948, SWCF1054, SWCF1354 SpringWell whole house water filters use the highest quality of coconut catalytic carbon that target the contaminants that we find in our water supplies today. Our systems are manufactured in an up-flow design giving the influent water optimal contact time so we can...
- Page 2 Additional Parts Included Pre-filter housing 5 micron sediment filter O-Ring for pre-filter housing Mounting bracket for pre-filter housing Spanner wrench for pre-filter housing Hose bib assembly Bypass valve 1” MNPT fittings PLEASE READ INSTRUCTIONS FULLY BEFORE INSTALLATION. Be sure to follow all applicable plumbing codes. The system must be installed on main water supply line.
-
Page 3: Product Specs
If the tank is not perfectly straight, carefully lift the tank straight up a few inches and tap it on the ground until the tank stands vertical and fits snuggly into the tank boot. Product Specs SWCF0948 Tank Width 9”... - Page 4 Soaking Instructions IMPORTANT! The carbon media inside the filter system MUST soak in water for a MINIMUM of 2 days before installation. To do so set the tank on a level surface in an area where it can get wet around the tank. Locate the bypass valve with the red arrows and the 1”...
-
Page 5: Carbon Rinse
Carbon Rinse After the carbon has soaked for 2 days take the bypass valve out of bypass into the service mode. Locate the hose bib assembly and connect it to the Inlet side. Connect a water hose to the opposite end of the hose bib assembly. Turn the water on slowly and only halfway on and allow the water to run for 15-20 minutes. ... - Page 6 Pre-Filter Setup / Installation This is the point where you will need to shut the main water supply off and adapt your plumbing in and through the system. We recommend you plumb a shut off valve before the pre-filter housing. Locate the area where the system is going to be installed.
- Page 7 Now connect the pre-filter housing head to the mounting bracket with the hex bolts provided. Plumb the water from the main water supply into the Inlet side of the pre-filter head (follow the arrows for water flow). Install lubed o-ring in groove on top of the blue pre-filter housing.
- Page 8 Carbon Filter Install Plumb the main water supply coming out of the pre-filter housing into the Inlet side. Now finish the plumbing by connecting the Outlet side back to the main plumbing supply. Place the bypass valve in bypass. (Example using SharkBite Fittings)
-
Page 9: Complete Install
Complete Install Once the plumbing is complete its time to start the system up. Double check all connections. The valve nuts should only be hand tight. Slowly turn the main water supply back on. Check for leaks. If there are no leaks slowly turn the bypass valve to the on position. -
Page 10: Warranty Information
Warranty Information For more information on our warranty, please visit www.springwellwater.com/warranty/...
