SpringWell ULTRA UWS1 Installation Instructions Manual page 8

Ultra Whole House Well Water Filter System Combo
IMPORTANT! The carbon media must be flushed on both tanks prior to install
Carbon Flush Instructions
Conditioner
Carbon Filter
Tank (FS)
Tank (CF)
16) Switch off the bypass on the
tanks. Note: Some water may be
released from the 48-hour pre-
soak.
19) Run water through the tank
until the water runs clear.
This step will require the materials listed below
Hose Bib
Assembly
17) Attach the hose bib
assembly onto the inlet port
on the tank.
20) Switch the hose and
hose bib to the outlet side
now and flush with water in
the opposite direction until
the water runs clear.
Questions? Call (800)-589-5592
Lawn Hose
Connected to Faucet
18) Connect the hose to the
hose bib assembly.
21) Repeats steps 16 through
20 on both tanks
Bypass Operation
Bypass on, water does
not flow through tank
Bypass off, water
flows through tank
8
