SpringWell ULTRA UWS1 Installation Instructions Manual page 16

Ultra Whole House Well Water Filter System Combo
Note: Ensure there are no kinks
or pinches on the drain line to
avoid issues with drainage.
67) Connect a corrugated water
connector to the incoming side
of the pre-filter.
70) Connect the other end to
the inlet on the softening tank.
Note: The inlet and outlet on
this tank are opposite the well
water filter.
Installing the Tanks – Part 2
This step will require the materials listed below
Tank
2
Wrench
Carbon Filter
(Tank 2)
68) Connect the other end of
the connector to the outgoing
side from the well water filter.
71) Connect the fourth water
connector to the outgoing side
of the carbon filter tank.
Questions? Call (800)-589-5592
Plumbers Tape
1-inch (24-inch Long) Corrugated
Water Connectors (x4)
69) Connect a water connector to
the outgoing side of the pre-filter.
72) Position the softening tank
next to the carbon filter tank.
16
