Setpoint range
For more information about Setpoint range, see
# Code
Leaving water temperature range for the main leaving water temperature zone (=
the leaving water temperature zone with the lowest leaving water temperature in
heating operation and the highest leaving water temperature in cooling
operation)
[2.8.1] [9-01]
[2.8.2] [9-00]
[2.8.3] [9-02]
[2.8.4] [9-03]
Control
The control type for the additional zone is read only. It is determined by the control
type of the main zone.
4
See "9.5.3 Main zone" [
# Code
[3.9] N/A
Thermostat type
Only applicable in external room thermostat control.
Also see "9.5.3 Main zone" [
# Code
[3.A] [C‑06]
Leaving water temperature: Delta T
For more information, see
Heating minimum:
▪ 15°C~37°C
Heating maximum:
▪ [2‑0C]=2 (emitter type main zone = radiator)
37°C~70°C
▪ Otherwise: 37°C~55°C
Cooling minimum:
▪ 5°C~18°C
Cooling maximum:
▪ 18°C~22°C
128].
Control
▪ Leaving water if the control type of the
main zone is Leaving water.
▪ External room thermostat if the control
type of the main zone is:
- External room thermostat,or
- Room thermostat.
4
128].
External room thermostat type for the additional
zone:
▪ 1: 1 contact. Connected to only 1 digital
input (X2M/35a)
▪ 2: 2 contacts. Connected to 2 digital inputs
(X2M/34a and X2M/35a)
4
"9.5.3 Main zone" [ 128].
4
"9.5.3 Main zone" [ 128].
