# Code
[3.1] N/A
Heating schedule
Define a heating temperature schedule for the additional zone via [3.2] Heating
schedule.
See "9.3.7 Schedule screen:
Cooling schedule
Define a cooling temperature schedule for the additional zone via [3.3] Cooling
schedule.
See "9.3.7 Schedule screen:
Setpoint mode
The setpoint mode of the additional zone can be independently set from the
setpoint mode of the main zone.
4
See "Setpoint mode" [ 129].
# Code
[3.4] N/A
WD curve type
The weather dependent curve can be defined using the 2-points method or the
Slope-Offset method.
Also see "9.4.2 2-points
The curve type in the menu of the additional zone is read only. It corresponds to
the curve type that is in use for the main zone. Thus, changing the curve type for
the additional zone must be done in the menu of the main zone: [2.E] WD curve
type.
Also see "9.5.3 Main zone" [
# Code
[2.E] N/A
Heating WD curve
Set weather-dependent heating for the additional zone (if [3.4]=1 or 2):
Schedule
▪ No
▪ Yes
4
Example" [ 114].
4
Example" [ 114].
Setpoint mode
▪ Fixed
▪ WD heating, fixed cooling
▪ Weather dependent
4
curve" [ 119] and "9.4.3 Slope-offset
4
128].
▪ 2-points
▪ Slope-Offset
9 Configuration
|
Description
Description
4
curve" [ 120].
Description
