Specifications

Camera
Lens
HFOV (Angle of
View)
Network
Network
Cabling Type
Connector
ONVIF®
Security
Protocols
Streaming Protocols
Device Management
Protocols
Mechanical
Dimensions
L x W x H
Max. Ceiling
Thickness
Camera Weight with
In-ceiling Mounting
Bracket
Body
Housing
Finish
Adjustment Range
Electrical
Specifications
2.8mm, F1.2, IR Corrected
1.3 MP: (5:4) 74°; (16:9) 110°
2.0 MP: (5:4) 74°; (16:9) 110°
3.0 MP: (5:4) 94°; (16:9) 100°, (4:3) 100°
100Base-TX
CAT5
RJ-45
ONVIF compliant with version 1.02, 2.00, Profile S (www.onvif.org)
Password protection, HTTPS encryption, digest authentication, WS authentication,
user access log, 802.1x port based authentication
IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP,
DHCP, Zeroconf, ARP
RTP/UDP, RTP/UDP multicast, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP,
RTP/RTSP/HTTPS/TCP, HTTP
SNMP v2c
SNMP v3
In-ceiling Mount: 89 mm x 89 mm x 39 mm (3.5" x 3.5" x 1.5")
In-ceiling Mount: 25 mm (1")
H4M-D1 - 152 g (0.34 lbs)
Polycarbonate and aluminum
Polycarbonate
Cool grey, black
360° pan, -5° to 75° tilt, ±115° azimuth
24
