Installation

Required Tools and Materials

The following tools are required to complete the installation but are not included in the package:
No. 2 Phillips screwdriver — for attaching camera to an electrical box or mounting surface.
l

Camera Package Contents

Ensure the package contains the following:
Avigilon H4 Mini Dome Camera (H4M-D), the "camera".
l
The following accessories are included but not required for an installation using a ceiling mount
adapter:
2 screws and anchors for solid walls
l
Surface mount bezel
l
Ensure the low-profile in-ceiling mounting adapter package (H4M-MT-DCIL1) contains the following:
In-ceiling mounting adapter for an H4 Mini Dome Camera
l
In-ceiling mounting template sticker
l
Low-profile bezel
l

Using the In-Ceiling Mounting Adapter

If the camera needs to be installed into a ceiling, you can disregard the surface mount adapter that is
provided with the camera and use the in-ceiling mounting adapter instead.
Note: The maximum supported mounting surface thickness for the in-ceiling mounting adapter is 25
mm (1").
Installation
10
