7.3.2. Speaker

This window is used to adjust the speaker volume. With a minimum of 20% the general volume cannot be
muted completely. If you want to completely mute the system volume, you can set this using chapter "6.1.
Configuring inputs".
If the buzzer is disabled at an input connection, the
external buzzer will not sound the alarm either.
Adjusting the speaker
• Go to 'Settings'.
• In de navigation, scroll to 'Speaker'.
• Press 'Change'.
• Move the bar to the desired volume.
• Press 'Save'.

7.3.3. Outputs

The Octalarm-Touch has two open drain output
connectors and two relay output connectors. These
can be set to function as:
• External buzzer
The output connector will respond in the same
way as the Octalarm-Touch buzzer. This means
that when the Octalarm-Touch buzzer is enabled,
the output connector is powered.
• External flash light
When the alarm is active, the output connector is
powered.
Overview of output connectors
Relay contact
Open drain output
Changing output connectiors
• Go to 'Settings'.
• In the navigation, scroll to 'Outputs'.
• Press 'Change'.
• Next, for both the relay outputs and for open collector, where applicable, select None | External buzzer
| Flash light
• Press 'Save'.

7.3.4. Factory settings

The installer and the administrator can clear all settings of the Octalarm-Touch. This feature is useful
when, for example, the Octalarm-Touch is taken to another location. The log will not be deleted when the
system is reset to the factory settings.
Restoring the factory settings
• Go to 'Settings'.
• In the navigation, scroll to 'Factory settings'.
• Press 'Restore'.

7.3.5. Software update

The software for the Octalarm-Touch is updated
continually. This may be to improve usage, to resolve
problems, or to add new options. It is important that
the Octalarm-Touch has the latest software version.
You can check if your Octalarm-Touch is up-to-date
under 'Settings' | 'Software update'. This is also
where you can find the release notes, which contain
the changes in each version in the version history.
Manual Octalarm-Touch | Back to
Max load
Max switching voltage
Max load current
Output voltage
Protection
index
30VDC / 2A, 30VAC / 1A (resistive load)
42V / 300mA
350mA
12V / 120mA
Short circuit, thermal
Page 14
