TuffStuff Apollo Series Assembly Instructions Manual page 8

Step 4 Swivel Foam Roll Tube and Seat Pad Assembly
A
Attach the Swivel Foam Roll Tube (#17) to the Pivot Arm (#11) and secure it into place using hardware shown. Next,
insert the Aluminum Collar 2.031 ID (#19) and the Foam Roll 2 X 5 1/2 X 18 (#6) to the Swivel Foam Roll Tube (#17)
and secure them into place using hardware shown.
B
Attach the Seat Pad (#15) to the Main Frame (#13) using hardware shown.
Item #
6 FOAM ROLL 2 X 5 1/2 X 18
15 SEAT PAD
17 SWIVEL FOAM ROLL TUBE 22 1/4
19 ALUMINUM COLLAR 2.031 ID X 2.584 OD
23 ALUMINUM WASHER 3/8 X 2.584 OD X .15 THK.
28 BUTTON HEAD SOCKET CAP SCREW B/O 3/8-16 X 1
7
Description
Assembly List
Qty. Item #
1 30 CHROME WASHER 3/8 X 1 1/2
1 36 FLAT WASHER SAE B/O 3/8"
1 39 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2
1 60 SOCKET SET SCREW ALLOY 10-32 X 1/4
1 64 SPLIT LOCK WASHER B/O 3/8"
2
Description
Ab/Back Station
Qty.
1
2
2
2
2
