5.4.1
Settings
Item
Symbol Description
1
2
3
4
5
6
7
8
9
10
11
12
099-010268-EW501
28.03.2011
0
Button, Program screen
Button, Functional sequence screen
Button, Function screen
Button, System screen
Button, Notes screen
Button, Index welding screen
Button, Operating mode screen
Button, I/O list screen
To monitor input and output signals
Button, Main menu
Button, Manual screen
Button, Automatic screen
Button, Accessories screen
Design and function
Figure 5-5
Main menu
